9485FRUsFRU#CRU

HDDTray(allmodels)

41R62912

FDDcable,325mm,(allmodels)

41A71822

Cabel-SATA457mm(RoHS)(allmodels)

43N90132

Cabel-SATA250mm(RoHS)(allmodels)

43N90122

OptionalHDDBracketAsm(allmodels)

41R61062

EMCShield(allmodels)

41N80802

EMCShield(allmodels)

41N80782

RearIOshieldATX,forRX780,Atlantic(allmodels)

41R6383N

IntrusionSwitchAsm(allmodels)

41R61162

TempSensecableforArmstrong(460mm)(allmodels)

41R25092

Blank5.25"Bezel(allmodels)

41N80772

AsmChassisWithoutIBMMarkAtlantic(allmodels)

41R6408

ODD/FDD/CardreaderRetainers(allmodels)

43N93512

AMDthermalKIT(allmodels)

41R64072

CableClip,FW-6D(allmodels)

43N94622

9485Keyboards(LenovoPreferredProUSB--withouthub)FRU#

CRU

Tier

USBFULL--USEnglish(modelsB3HB2HD1HD2MD2AD2QD3MD3AD3QD4AD4QD5A

D5QD6MD6AD6QD7MD7AD7QD8AD8QE2UA6MA6AA6QA7AA7QA5GB8GB9G

B9AA2UA4UA1UA1LA1MA1AA1QA1HA1RF3MF3AF3QF4MF4AF4QF5MF5A

F5QH2AH2QH4AH4QH5MH5AH5QH6MH6AH6QF8UF9UH1UE4UE5UE6UE7U

E8UE9UF1UF2UF6GF7GH8UH9UJ1U)

41A52891

USBFULL--Arabic(modelsA5GB8GB9GF6GF7G)

41A52901

USBFULL--Arabic/French(modelsA5GB8GB9GF6GF7G)

41A52911

USBFULL--Belgian/French(modelsA5GA5GB8GB8GB9GB9GF6GF6GF7GF7G)

41A52921

USBFULL--BelgiumEnglish(modelsA5GB8GB9GF6GF7G)

41A52931

USBFULL--BrazilianPortuguese(modelsA8PA9PA1PE3PE1P)

41A52941

USBFULL--Bulgarian(modelsA5GB8GB9GF6GF7G)

41A52951

USBFULL--Chinese/US(modelsB4VB7VA1BA1VB5VB6V)

41A52961

USBFULL--Czech(ABB)(modelsA5GB8GB9GF6GF7G)

41A52971

USBFULL--Danish(modelsA5GB8GB9GF6GF7G)

41A52981

USBFULL--Dutch(modelsA5GB8GB9GF6GF7G)

41A52991

USBFULL--French(modelsA5GB8GB9GF6GF7G)

41A53001

USBFULL--FrenchCanadian(modelsE2FA5GB8GB9GA2FA4FA1FF8FF9FH1FE4F

E5FE6FE7FE8FE9FF1FF2FF6GF7GH8FH9FJ1F)

41A53011

USBFULL--FrenchCanadian(modelsE2FA5GB8GB9GA2FA4FA1FF8FF9FH1FE4F

E5FE6FE7FE8FE9FF1FF2FF6GF7GH8FH9FJ1F)

41A53021

USBFULL--German(modelsA5GB8GB9GF6GF7G)

41A53031

USBFULL--Greek(modelsA5GB8GB9GF6GF7G)

41A53041

USBFULL--Greek/US(modelsA5GB8GB9GF6GF7G)

41A53051

Chapter10FRUlists291
