9623Keyboards(LenovoPreferredProUSB--withouthub)FRU#
CRU
Tier
USBFULL--Dutch(modelsA1GA2G)
41A52991
USBFULL--French(modelsA1GA2G)
41A53001
USBFULL--FrenchCanadian(modelsA1GA2G)
41A53011
USBFULL--FrenchCanadian(modelsA1GA2G)
41A53021
USBFULL--German(modelsA1GA2G)
41A53031
USBFULL--Greek(modelsA1GA2G)
41A53041
USBFULL--Greek/US(modelsA1GA2G)
41A53051
USBFULL--Hebrew(modelsA1GA2G)
41A53061
USBFULL--Hungarian(modelsA1GA2G)
41A53071
USBFULL--Iceland(modelsA1GA2G)
41A53081
USBFULL--Italy(modelsA1GA2G)
41A53091
USBFULL--Japanese(models)
41A53101
USBFULL--Korean(models)
41A53111
USBFULL--LASpanish(models)
41A53121
USBFULL--Norwegian(modelsA1GA2G)
41A53131
USBFULL--Polish(modelsA1GA2G)
41A53141
USBFULL--Portugese(modelsA1GA2G)
41A53151
USBFULL--Romanian(modelsA1GA2G)
41A53171
USBFULL--Russian/Cyrillic(modelsA1GA2G)
41A53181
USBFULL--Serbian/Cyrillic(modelsA1GA2G)
41A53191
USBFULL--Slovak(modelsA1GA2G)
41A53201
USBFULL--Spanish(modelsA1GA2G)
41A53211
USBFULL--Swedish/Finnish(modelsA1GA2G)
41A53221
USBFULL--SwissF/G(modelsA1GA2G)
41A53231
USBFULL--Thailand(models)
41A53241
USBFULL--Turkish(modelsA1GA2G)
41A53251
USBFULL--Turkish(modelsA1GA2G)
41A53261
USBFULL--UKEnglish(modelsA1GA2G)
41A53271
USBFULL--USEuro(modelsA1GA2G)
41A53281
USBFULL--Slovenian(models)
41A53291
9623Keyboards(LenovoFingerprintReaderUSB)FRU#
CRU
Tier
USEnglish(models)
41R00381
Arabic(models)
41R00391
Arabic/French(models)
41R00401
Belgian/French(models)
41R00411
BelgiumEnglish(models)
41R00421
BrazilianPortuguese(models)
41R00431
322ThinkCentreHardwareMaintenanceManual
