ThinkCentre Hardware Maintenance Manual
Note: Before using this information and the product it supports, be sure to read and understand the information under “Notices,” on page 313. Fourth Edition (April, 2009) © Copyright Lenovo 2008, 2009. All rights reserved. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.
Contents Chapter 1. About this manual . . . . . 1 Important safety information . . . . . . Important information about replacing RoHS compliant FRUs . . . . . . . . . . . . . 1 . . . 2 POST error codes . . . . . Miscellaneous error messages . Undetermined problems . . . . . . . . . . . . . . . . . . . . . . 74 . 76 . 77 Chapter 8. Replacing FRUs . . . . . . 79 Chapter 2. Safety information . . . . . 3 . 42 . 42 Locations . . . . . . . . . . . . . . .
Appendix. Notices . . . . . . . . . 313 Television output notice . iv . . . Hardware Maintenance Manual . . . . . . 314 Trademarks . . . . . . . . . . . . . .
Chapter 1. About this manual This manual contains service and reference information for ThinkCentre® computer machine types listed on the front cover. This manual is intended only for trained Service Providers who are familiar with Lenovo® computer products. Note: Be sure to read and understand the Chapter 2, “Safety information,” on page 3 before using the information in this manual. The “Symptom-to-FRU Index” chapter and the “Additional service information” chapter apply to all ThinkCentre computers.
Important information about replacing RoHS compliant FRUs RoHS, the Restriction of Hazardous Substances in Electrical and Electronic Equipment Directive (2002/95/EC) is a European Union legal requirement affecting the global electronics industry. RoHS requirements must be implemented on Lenovo products placed on the market and sold in the European Union after June, 2006. Products on the market before June, 2006 are not required to have RoHS compliant parts.
Chapter 2. Safety information This chapter contains the safety information that you need to be familiar with before servicing a computer. General safety Follow these rules to ensure general safety: v Observe good housekeeping in the area of the machines during and after maintenance. v When lifting any heavy object: 1. Ensure you can stand safely without slipping. 2. Distribute the weight of the object equally between your feet. 3. Use a slow lifting force.
CAUTION: Electrical current from power, telephone, and communication cables can be hazardous. To avoid personal injury or equipment damage, disconnect the attached power cords, telecommunication systems, networks, and modems before you open the server/workstation covers, unless instructed otherwise in the installation and configuration procedures. Observe the following rules when working on electrical equipment. Important: Use only approved tools and test equipment.
v Always look carefully for possible hazards in your work area. Examples of these hazards are moist floors, nongrounded power extension cables, power surges, and missing safety grounds. v Do not touch live electrical circuits with the reflective surface of a plastic dental mirror. The surface is conductive; such touching can cause personal injury and machine damage.
If any unsafe conditions are present, you must determine how serious the apparent hazard could be and whether you can continue without first correcting the problem. Consider these conditions and the safety hazards they present: v Electrical hazards, especially primary power (primary voltage on the frame can cause serious or fatal electrical shock).
v Prevent the part from touching your clothing. Most clothing is insulative and retains a charge even when you are wearing a wrist strap. v Use the black side of a grounded work mat to provide a static-free work surface. The mat is especially useful when handling ESD-sensitive devices. v Select a grounding system, such as those listed below, to provide protection that meets the specific service requirement. Note: The use of a grounding system is desirable but not required to protect against ESD damage.
v Connect to properly wired outlets any equipment that will be attached to this product. v When possible, use one hand only to connect or disconnect signal cables. v Never turn on any equipment when there is evidence of fire, water, or structural damage. v Disconnect the attached power cords, telecommunications systems, networks, and modems before you open the device covers, unless instructed otherwise in the installation and configuration procedures.
CAUTION: When replacing the lithium battery, use only Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.
CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.
Chapter 2.
12 Hardware Maintenance Manual
≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) 2 1 Chapter 2.
PERIGO A corrente elétrica proveniente de cabos de alimentação, de telefone e de comunicações é perigosa. Para evitar risco de choque elétrico: v Não conecte nem desconecte nenhum cabo ou execute instalação, manutenção ou reconfiguração deste produto durante uma tempestade com raios. v Conecte todos os cabos de alimentação a tomadas elétricas corretamente instaladas e aterradas. v Todo equipamento que for conectado a este produto deve ser conectado a tomadas corretamente instaladas.
CUIDADO: Ao substituir a bateria de lítio, utilize apenas uma bateria com Número de Peça 33F8354 ou um tipo de bateria equivalente recomendado pelo Se o seu sistema possui um módulo com uma bateria de lítio, substitua-o apenas por um módulo do mesmo tipo e do mesmo fabricante. A bateria contém lítio e pode explodir se não for utilizada, manuseada ou descartada de maneira correta.
CUIDADO: O botão de controle de alimentação do dispositivo e o botão para ligar/desligar da fonte de alimentação não desligam a corrente elétrica fornecida ao dispositivo. O dispositivo também pode ter mais de um cabo de alimentação. Para remover toda a corrente elétrica do dispositivo, assegure que todos os cabos de alimentação estejam desconectados da fonte de alimentação.
Chapter 2.
2 1 18 Hardware Maintenance Manual
Chapter 2.
2 1 20 Hardware Maintenance Manual
DANGER Le courant électrique provenant de l’alimentation, du téléphone et des câbles de transmission peut présenter un danger. Pour éviter tout risque de choc électrique : v Ne manipulez aucun câble et n’effectuez aucune opération d’installation, d’entretien ou de reconfiguration de ce produit au cours d’un orage. v Branchez tous les cordons d’alimentation sur un socle de prise de courant correctement câblé et mis à la terre.
ATTENTION: Remplacer la pile au lithium usagée par une pile de référence identique exclusivement, (référence 33F8354), ou suivre les instructions du fabricant qui en définit les équivalences. Si votre système est doté d’un module contenant une pile au lithium, vous devez le remplacer uniquement par un module identique, produit par le même fabricant. La pile contient du lithium et peut exploser en cas de mauvaise utilisation, de mauvaise manipulation ou de mise au rebut inappropriée.
≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ATTENTION: Soulevez la machine avec précaution. ATTENTION: L’interrupteur de contrôle d’alimentation de l’unité et l’interrupteur dubloc d’alimentation ne coupent pas le courant électrique alimentantl’unité. En outre, le système peut être équipé de plusieurs cordonsd’alimentation. Pour mettre l’unité hors tension, vous devez déconnectertous les cordons de la source d’alimentation. 2 1 Chapter 2.
VORSICHT An Netz-, Telefon- und Datenleitungen können gefährliche Spannungen anliegen. Aus Sicherheitsgründen: v Bei Gewitter an diesem Gerät keine Kabel anschließen oder lösen. Ferner keine Installations-, Wartungs- oder Rekonfigurationsarbeiten durchführen. v Gerät nur an eine Schutzkontaktsteckdose mit ordnungsgemäß geerdetem Schutzkontakt anschließen. v Alle angeschlossenen Geräte ebenfalls an Schutzkontaktsteckdosen mit ordnungsgemäß geerdetem Schutzkontakt anschließen.
CAUTION: Eine verbrauchte Lithiumbatterie nur durch eine Batterie mit der Teilenummer 33F8354 oder eine gleichwertige, vom Hersteller empfohlene Batterie ersetzen. Enthält das System ein Modul mit einer Lithiumbatterie, dieses nur durch ein Modul desselben Typs und von demselben Hersteller ersetzen. Die Batterie enthält Lithium und kann bei unsachgemäßer Verwendung, Handhabung oder Entsorgung explodieren. Die Batterie nicht: v mit Wasser in Berührung bringen. v über 100 C erhitzen.
≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ACHTUNG: Arbeitsschutzrichtlinien beim Anheben der Maschine beachten. ACHTUNG: Mit dem Netzschalter an der Einheit und am Netzteil wird die Stromversorgung für die Einheit nicht unterbrochen. Die Einheit kann auch mit mehreren Netzkabeln ausgestattet sein. Um die Stromversorgung für die Einheit vollständig zu unterbrechen, müssen alle zum Gerät führenden Netzkabel vom Netz getrennt werden.
Chapter 2.
28 Hardware Maintenance Manual
2 1 Chapter 2.
PERICOLO La corrente elettrica proveniente dai cavi di alimentazione, del telefono e di comunicazione può essere pericolosa. Per evitare il rischio di scosse elettriche: v Non collegare o scollegare qualsiasi cavo oppure effettuare l’installazione, la manutenzione o la riconfigurazione del prodotto durante un temporale. v Collegare tutti i fili elettrici a una presa di alimentazione correttamente cablata e dotata di messa a terra.
ATTENZIONE: Quando si sostituisce la batteria al litio, utilizzare solo il Numero parte 33F8354 o un tipo di batteria equivalente consigliato dal produttore. Se sul sistema è presente un modulo che contiene una batteria al litio, sostituirlo solo con un tipo di modulo dello stesso tipo della stessa casa di produzione. La batteria contiene litio e può esplodere se usata, maneggiata o smaltita in modo non corretto.
≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ATTENZIONE: Prestare attenzione nel sollevare l’apparecchiatura. ATTENZIONE: Il pulsante di controllo dell’alimentazione presente sull’unità e l’interruttore dell’alimentatore non disattivano l’alimentazione corrente fornita all’unità. E’ possibile che l’unità disponga di più cavi di alimentazione. Per disattivare l’alimentazione dall’unità, accertarsi che tutti i cavi di alimentazione siano scollegati dalla fonte di alimentazione.
Chapter 2.
2 1 34 Hardware Maintenance Manual
PELIGRO La corriente eléctrica procedente de cables de alimentación, teléfonos y cables de comunicación puede ser peligrosa. Para evitar el riesgo de descarga eléctrica: v No conecte ni desconecte los cables ni realice ninguna tarea de instalación, mantenimiento o reconfiguración de este producto durante una tormenta eléctrica. v Conecte todos los cables de alimentación a tomas de corriente debidamente cableadas y conectadas a tierra.
PRECAUCIÓN: Cuando sustituya una batería de litio, utilice solamente una batería número de pieza 33F8354 u otra de tipo equivalente recomendada por el fabricante. Si su sistema dispone de un módulo que contiene una batería de litio, reemplácelo sólo con el mismo tipo de módulo, del mismo fabricante. La batería contiene litio y puede explotar si no se utiliza, manipula o desecha correctamente.
≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) PRECAUCIÓN: Adopte procedimientos seguros al levantar el equipo. PRECAUCIÓN: El botón de control de alimentación del dispositivo y el interruptor de alimentación de la fuente de alimentación no desconectan la corriente eléctrica suministrada al dispositivo. Además, el dispositivo podría tener más de un cable de alimentación.
38 Hardware Maintenance Manual
Chapter 3. General information This chapter provides general information that applies to all machine types supported by this manual. ThinkVantage Productivity Center Note: This section applies only to computer models that have an internal hard disk drive and preinstalled software from Lenovo. Use the ThinkVantage® Productivity Center program which is preinstalled on most ThinkCentre products for general information about the use, operation, and maintenance of the computer.
Specifications This section lists the physical specifications for your computer. Dimensions Width: 275 mm (10.83 inches) Height: 80 mm (3.15 inches) Depth: 238 mm (9.37 inches) Weight Note: The weight does not include the power supply or any external cables. Maximum configuration as shipped: 4.18 kg (9.
Chapter 4. General checkout Attention The drives in the computer you are servicing might have been rearranged or the drive startup sequence changed. Be extremely careful during write operations such as copying, saving, or formatting. Data or programs can be overwritten if you select an incorrect drive. General error messages appear if a problem or conflict is found by an application program, the operating system, or both.
Checking for power problems If the computer does not turn on when the power switch is pressed, use the following procedure to help troubleshoot: 1. Press the power switch to turn on the computer. Check the power indicator LED next to the power switch. v If the LED is illuminated (on), the computer power is OK. Attempt to run the diagnostics. See “Running diagnostics from the disc” on page 46. v If the LED is not illuminated (off), go to step 2 2.
v Operating system software – Type and version level Note: To eliminate confusion, identical systems are considered identical only if they: 1. Are the exact machine type and models 2. Have the same BIOS level 3. Have the same adapters/attachments in the same locations 4. Have the same address jumpers/terminators/cabling 5. Have the same software versions and levels 6. Have the same Diagnostic Diskettes (version) 7. Have the same configuration options set in the system 8.
44 Hardware Maintenance Manual
Chapter 5. Diagnostics Note: The diagnostic programs are only available on computers that have an internal hard disk drive and preinstalled software from Lenovo. Diagnostic programs are used to test hardware components of your computer and report operating-system-controlled settings that can cause hardware failures.
PC-Doctor for Windows PE The PC-Doctor for Windows PE diagnostic program is part of the Rescue and Recovery® workspace on each Lenovo computer. Use the PC-Doctor for Windows PE if you are unable to start the Windows operating system or if the Lenovo System Toolbox has not been successful in isolating a possible problem. Running diagnostics from the Rescue and Recovery workspace You can run the PC-Doctor for Windows PE diagnostic program from the Rescue and Recovery workspace.
Note: When the program finishes, be sure to remove the disc from the optical drive. 4. Select the diagnostic test you want to run. Press the F1 key for additional help. Navigating through the diagnostics programs Use the cursor movement keys to navigate within the menus. v The Enter key is used to select a menu item. v The Esc key is used to back up to the previous menu. v For online help select F1. Running tests There are four ways to run the diagnostic tests.
v Date: Contains the date when the diagnostic test was run. The date is retrieved from CMOS and displayed using the YYYYMMDD format. v ChkDigits: Contains a 2-digit check-digit value to ensure the following: – Diagnostics were run on the specified date. – Diagnostics were run on the specified computer. – The diagnostic error code is recorded correctly. v Text: Description of the error. Note: See “Diagnostic error codes” on page 54 for error code listings.
Chapter 6. Using the Setup Utility The Setup Utility program is used to view and change the configuration settings of your computer, regardless of which operating system you are using. However, the operating-system settings might override any similar settings in the Setup Utility program. Starting the Setup Utility program To start the Setup Utility program, do the following: 1. If your computer is already on when you start this procedure, shut down the operating system and turn off the computer. 2.
Password considerations A password can be any combination of up to 64 (1 to 64) alphabetic and numeric characters. For security reasons, it is recommended to use a strong password that cannot be easily compromised.
Enabling or disabling a device This section provides information on how to enable or disable user access to the following devices: Serial ATA External SATA Port Legacy Diskette A (some models) When this feature is set to Disabled, all devices connected to the SATA connectors (such as hard disk drives or the optical drive) are disabled and will not be displayed in the system configuration. When this feature is set to Disabled, the device connected to the External SATA connector cannot be accessed.
Selecting or changing the startup device sequence To view or permanently change the configured startup device sequence, do the following: 1. Start the Setup Utility program. See “Starting the Setup Utility program” on page 49. 2. Select Startup → Startup Sequence. See the information displayed on the right side of the screen. 3. Select the devices for the Primary Startup Sequence, the Automatic Startup Sequence, and the Error Startup Sequence. 4.
Chapter 7. Symptom-to-FRU index The Symptom-to-FRU index lists error symptoms and possible causes. The most likely cause is listed first. Always begin with the Chapter 4, “General checkout,” on page 41. You can use this index to help you decide which FRUs are needed when servicing a computer. If you are unable to correct the problem using this index, go to “Undetermined problems” on page 77. Notes: 1. If you have both an error message and an incorrect audio response, diagnose the error message first. 2.
Diagnostic error codes Refer to the following diagnostic error codes when using the diagnostic tests. See “Running tests” on page 47 for the specific type for information about the Diagnostic programs. In the following index, X can represent any number. Diagnostic Error Code FRU/Action 000-000-XXX BIOS Test Passed No action 000-002-XXX BIOS Timeout 1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 310 2. System board 000-024-XXX BIOS Addressing test failure 1. Flash the system.
Diagnostic Error Code FRU/Action 000-039-XXX BIOS DMI data error 1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 310 2. System board 000-195-XXX BIOS Test aborted by user Information only Re-start the test, if necessary 000-196-XXX BIOS test halt, error threshold exceeded 1. Press F3 to review the log file 000-197-XXX BIOS test warning 1. Make sure the component that is called out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2.
Diagnostic Error Code FRU/Action 001-025-XXX System Checksum Value error 1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 310 2. System board 001-026-XXX System FLASH data error 1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 310 2. System board 001-027-XXX System Configuration/Setup error 1. Run Setup 2. Flash the system. See “Updating (flashing) BIOS from a disc” on page 310 3.
Diagnostic Error Code FRU/Action 001-198-XXX System test aborted 1. If a component is called out, make sure it is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Flash the system and retest. See “Updating (flashing) BIOS from a disc” on page 310 3. Go to “Undetermined problems” on page 77 001-199-XXX System test failed, cause unknown 1. Go to “Undetermined problems” on page 77 2. Flash the system and re-test 3.
Diagnostic Error Code FRU/Action 001-278-XXX System IRQ11 failure 1. Device on IRQ11 001-279-XXX System IRQ12 failure 1. Device on IRQ12 001-280-XXX System IRQ13 failure 1. Device on IRQ13 001-281-XXX System IRQ14 (hard disk drive) failure 1. Hard disk drive cable 001-282-XXX System IRQ15 failure 1. Device on IRQ15 001-286-XXX 001-287-XXX 001-288-XXX System Timer failure System board 001-292-XXX System CMOS RAM error 1. Run Setup and re-test 001-293-XXX System CMOS Battery 1.
Diagnostic Error Code FRU/Action 005-024-XXX Video Addressing test failure 1. Video card, if installed 005-025-XXX Video Checksum Value error 1. Video card, if installed 005-027-XXX Video Configuration/Setup error 1. Run Setup 2. System board 2. System board 2. Video drivers update 3. Video card, if installed 4. System board 005-031-XXX Video Device Cable failure 1. Video cable 2. Monitor 3. Video card, if installed 4. System board 005-032-XXX Video Device Controller failure 1.
Diagnostic Error Code FRU/Action 005-199-XXX Video test failed, cause unknown 1. Go to “Undetermined problems” on page 77 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Replace component under function test 005-2XX-XXX 005-3XX-XXX Video subsystem error 1. Video card, if installed 006-000-XXX Diskette interface Test Passed No action 006-0XX-XXX Diskette interface error 1. Diskette drive Cable 2. System board 2. Diskette drive 3.
Diagnostic Error Code FRU/Action 015-015-XXX USB port External Loopback failure 1. Remove USB device(s) and re-test 015-027-XXX USB port Configuration/Setup error 1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 310 2. System board 2. System board 015-032-XXX USB port Device Controller failure System board 015-034-XXX USB port buffer allocation failure 1. Reboot the system 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3.
Diagnostic Error Code FRU/Action 015-199-XXX USB port test failed, cause unknown 1. Go to “Undetermined problems” on page 77 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Replace component under function test 018-000-XXX PCI Card Test Passed No action 018-0XX-XXX PCI Card Failure 1. Riser card, if installed 018-195-XXX PCI Card Test aborted by user 1. PCI card 018-196-XXX PCI Card test halt, error threshold exceeded 1.
Diagnostic Error Code FRU/Action 020-195-XXX PCI Test aborted by user Information only Re-start the test, if necessary 020-196-XXX PCI test halt, error threshold exceeded 1. Press F3 to review the log file 020-197-XXX PCI test warning 1. Make sure the component that is called out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Re-start the test to reset the log file 2. Re-run test 3. Replace the component that is called out in warning statement 4.
Diagnostic Error Code FRU/Action 025-02X-XXX 025-03X-XXX 025-04X-XXX IDE Interface failure 1. IDE signal cable 2. Check AC/DC power adapter 3. Reseat IDE signal cable 4. IDE device 5. System board 025-195-XXX IDE interface Test aborted by user Information only Re-start the test, if necessary 025-196-XXX IDE interface test halt, error threshold exceeded 1. Press F3 to review the log file 025-197-XXX IDE interface test warning 1. Make sure the component that is called out is connected and/or enabled.
Diagnostic Error Code FRU/Action 030-03X-XXX 030-04X-XXX SCSI interface error 1. SCSI signal cable 2. Check AC/DC power adapter 3. SCSI device 4. SCSI adapter card, if installed 5. System board 030-195-XXX SCSI interface Test aborted by user Information only Re-start the test, if necessary 030-196-XXX SCSI interface test halt, error threshold exceeded 1. Press F3 to review the log file 030-197-XXX SCSI interface test warning 1. Make sure the component that is called out is connected and/or enabled.
Diagnostic Error Code FRU/Action 035-197-XXX RAID interface test warning 1. Make sure the component that is called out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Re-run test 3. Replace the component that is called out in warning statement 4. Replace the component under test 035-198-XXX RAID interface test aborted 1. If a component is called out, make sure it is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2.
Diagnostic Error Code FRU/Action 071-197-XXX Audio port test warning 1. Make sure the component that is called out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Re-run test 3. Replace the component that is called out in warning statement 4. Replace the component under test 071-198-XXX Audio port test aborted 1. If a component is called out, make sure it is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2.
Diagnostic Error Code FRU/Action 080-198-XXX Game Port interface test aborted 1. If a component is called out, make sure it is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Go to “Undetermined problems” on page 77 080-199-XXX Game Port interface test failed, cause unknown 1. See “Undetermined problems” on page 77 2. Flash the system and re-test.
Diagnostic Error Code FRU/Action 086-199-XXX Mouse Port interface test failed, cause unknown 1. See “Undetermined problems” on page 77 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Replace component under function test 089-000-XXX Microprocessor Test Passed No action 089-XXX-XXX Microprocessor failure 1.
Diagnostic Error Code FRU/Action 170-197-XXX Voltage Sensor(s) test warning 1. Make sure the component that is called out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Re-run test 3. Replace the component that is called out in warning statement 4. Replace the component under test 170-198-XXX Voltage Sensor(s) test aborted 1. If a component is called out, make sure it is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2.
Diagnostic Error Code FRU/Action 175-198-XXX Thermal Sensor(s) test aborted 1. If a component is called out, make sure it is connected and/or enabled 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Go to “Undetermined problems” on page 77 175-199-XXX Thermal Sensor(s) test failed, cause unknown 1. See “Undetermined problems” on page 77 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3.
Diagnostic Error Code FRU/Action 215-XXX-XXX CD-ROM Drive error 1. CD-ROM Drive Cable 2. Check AC/DC power adapter voltages 3. CD-ROM drive 4. System board 217-000-XXX Hard Disk Drive Test Passed No action 217-25X-XXX 217-26X-XXX Hard Disk Drive (IDE) error 1. Hard Disk Drive Cable 2. Check AC/DC power adapter voltages 3. Reseat the hard disk drive cable 4. Hard Disk drive (IDE) 5. System board 217-28X-XXX 217-29X-XXX Hard Disk Drive (SCSI) error 1. Hard Disk Drive Cable 2.
Diagnostic Error Code FRU/Action 415-XXX-XXX Modem error Remove the Modem and re-test the system Beep symptoms Beep symptoms are tones or a series of tones separated by pauses (intervals without sound) during POST. The following tables describes beep symptoms. Beep Symptom FRU/Action 1, 2, or 3 beeps Reseat the memory modules. If the error persists, replace the memory modules one at a time until the failing module is determined.
POST error codes Each time you power-on the system, it performs a series of tests that check the operation of the system and some options. This series of tests is called the Power-On Self-Test, or POST. POST does the following operations. v Checks some basic system-board operations v Checks the memory operation v Starts the video operation v Verifies that the boot drive is working If the POST detects a problem, an error message appears on the screen.
POST Error Message Description/Action Press TAB to show POST screen Pressing the TAB key permits the user to toggle between the default POST display screen and a custom POST display screen. Error: Non-System disk or disk error Replace and press any key when ready The BIOS was unable to find a suitable boot device. Make sure the boot drive is properly connected to the computer. Make sure you have bootable media. Chapter 7.
Miscellaneous error messages Message/Symptom FRU/Action Changing display colors Display/Monitor Computer will not power-off. See “Checking for power problems” on page 42. 1. Power Switch 2. System Board 3. Riser card, if installed Computer will not PXE from server 1. Ensure that network is in startup sequence as first device or first device after diskette 2. Ensure that network adapter is enabled for PXE 3.
Message/Symptom FRU/Action Non-system disk or disk error-type message with a known-good diagnostic diskette. 1. Diskette Drive 2. System Board 3. Diskette Drive Cable Other display symptoms not listed above (including blank or illegible display) 1. Display 2. System Board Power-on indicator or hard disk drive in-use 1. Power switch/LED assembly light not on, but computer works correctly 2. System Board Printer problems 1. Printer 2.
78 Hardware Maintenance Manual
Chapter 8. Replacing FRUs This chapter provides step-by-step instructions for replacing major FRUs. Important Be sure to read and understand the Chapter 2, “Safety information,” on page 3 before replacing any FRU. These precautions and guidelines will help you work safely. FRU replacements are to be done only by trained service technicians.
Locations This section provides illustrations to help you locate the various connectors and components of your computer. Locating connectors on the front of the computer The following illustration shows the location of the connectors on the front of your computer. Note: Not all computer models have the following connectors. Figure 1.
Locating connectors on the rear of the computer The following illustration shows the locations of the connectors on the rear of the computer. Figure 2.
Locating components The following illustration shows the locations of the various components in the computer. Figure 3.
Locating parts on the system board The following illustration shows the locations of parts on the system board. Figure 4.
Opening the computer cover Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to open the computer cover.
Replacing the battery Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the battery.
6. Turn on the computer and all attached devices. 7. Use the Setup Utility program to set the date, time, and any passwords. See Chapter 6, “Using the Setup Utility,” on page 49. Replacing a memory module Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.
4. Insert the notched end 2 of the new memory module into the socket 1 . Press the memory module firmly, and pivot the memory module until it snaps into place. Make sure that the memory module is firmly fixed in the slot and does not move easily. Figure 9. Installing the new memory module 5. Go to “Completing the FRU replacement” on page 106. Chapter 8.
Replacing the adapter card Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the adapter card. Note: You need to remove the system board in order to replace the adapter card. To replace the adapter card: 1.
6. Rotate the adapter card retainer to the open position and remove the adapter card being replaced by pulling it out of the adapter card slot. Figure 11. Removing the adapter card 7. Remove the new adapter card from its static-protective package. 8. Install the new adapter card into the adapter card slot. Make sure that the adapter card is firmly fixed in the slot and does not move easily. 9. Close the adapter card retainer. 10.
Replacing the front audio and USB assembly Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the front audio and USB assembly. To replace the front audio and USB assembly: 1. Open the computer cover.
4. Note the front audio and USB assembly cables routing and remove the screw that secures the assembly to the chassis. Figure 13. Removing the front audio and USB assembly 5. Remove the failing front audio and USB assembly from the chassis. 6. Install the new front audio and USB assembly into the chassis and secure it with the screw. 7. Connect the front audio and USB assembly cables to the system board. 8.
To 1. 2. 3. replace the heat sink: Open the computer cover. See “Opening the computer cover” on page 84. Locate the heat sink. See “Locating components” on page 82. Remove the four screws that secure the heat sink to the system board. Note: Carefully remove the four screws from the system board to avoid any possible damage. The four screws cannot be removed from the heat sink. Figure 14. Removing the heat sink 4. Lift the failing heat sink off the system board. Notes: a.
Replacing the microprocessor Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the microprocessor. CAUTION: The heat sink and microprocessor might be very hot.
6. Lift the microprocessor straight up and out of the socket. Notes: a. Your microprocessor and socket might look different from the one illustrated. b. Note the orientation of the microprocessor in the socket. You can either look for the small triangle 1 on one corner of the microprocessor or note the orientation of the notches 2 on the microprocessor. This is important when installing the new microprocessor on the system board. c. Touch only the sides of the microprocessor.
8. Remove the protective cover 2 that protects the gold contacts on the new microprocessor 1 . 9. Hold the new microprocessor and align the notches on it with the tabs in the microprocessor socket, or align the small triangle on one corner with the corresponding beveled corner of the microprocessor socket. 10. Lower the new microprocessor straight down into the microprocessor socket on the system board. 11.
Replacing the system board Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the system board. CAUTION: The heat sink and microprocessor might be very hot.
7. Remove the adapter card from the failing system board. See “Replacing the adapter card” on page 88. 8. Remove the battery from the failing system board. See “Replacing the battery” on page 85. 9. Remove the microprocessor from the failing system board. See “Replacing the microprocessor” on page 93. 10. Remove the screws that secure the failing system board to the protective cover. 11. Lift the failing system board off the cover. 12.
3. Insert the tabs 1 of the socket cover into the hinged side of the socket, and then press the other side of the socket cover downward until the tabs 2 snap into position. Figure 18. Tabs on the microprocessor socket cover (bottom view) Figure 19.
Replacing the system fan Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the system fan. To replace the system fan: 1. Open the computer cover. See “Opening the computer cover” on page 84. 2.
6. Install the two short rubber mounts in the new system fan as shown. Figure 21. Installing the short rubber mounts 7. Install the two long rubber mounts into the rear of the chassis. Push the mounts through the holes of the chassis. If necessary, pull the mounts through the holes from inside the chassis. 8. To install the new system fan assembly into the chassis, align the open holes in the system fan assembly with the long rubber mounts in the chassis.
Replacing the hard disk drive Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the hard disk drive if your computer has one.
7. To install the new hard disk drive into the plastic bracket, flex the bracket and align pin 1 , pin 2 , pin 3 , and pin 4 on the bracket with the holes in the hard disk drive. Do not touch the circuit board 5 on the bottom of the hard disk drive. Figure 24. Installing the hard disk drive into the bracket 8. 9. 10. 11. 102 Connect the signal and power cables to the rear of the new hard disk drive. Slide the new hard disk drive into the drive bay until it snaps into position.
Replacing the optical drive Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the optical drive. To replace the optical drive: 1. Open the computer cover. See “Opening the computer cover” on page 84. 2.
5. Remove the retainer bracket from the failing drive and install it on the new optical drive. Figure 27. Retainer bracket for optical drive 6. Slide the new optical drive into the drive bay until it snaps into position. Figure 28. Replacing the optical drive 7. Connect the signal and power cables to the drive. 8. To reinstall the front bezel, align the plastic tabs on the bottom of the bezel with the corresponding holes in the chassis, then pivot the bezel inward until it snaps into position. 9.
Replacing the internal speaker Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the internal speaker. To 1. 2. 3. replace the internal speaker: Open the computer cover.
Completing the FRU replacement This section provides instructions on how to complete the parts replacement. After completing all parts replacement, you need to close the cover and reconnect cables, such as power cords. Depending on the parts replaced, you might need to confirm the updated information in the Setup Utility program. See Chapter 6, “Using the Setup Utility,” on page 49. To complete the parts replacement: 1.
3. Close the computer cover. Figure 31. Closing the computer cover 4. If a cover lock is installed, lock the cover. 5. Reconnect the external cables and power cords to the computer. See “Locating connectors on the rear of the computer” on page 81. 6. To update your configuration, see Chapter 6, “Using the Setup Utility,” on page 49. Chapter 8.
108 Hardware Maintenance Manual
Chapter 9. FRU lists This chapter lists the information on the field replaceable units (FRUs). Attention: Be sure to read and understand all the safety information before replacing any FRUs. Note: In the following tables, a customer replaceable unit (CRU) is identified as either ″1″, ″2″, or "N" in the CRU column. ″N″ means that the part is not a CRU, ″1″ means that the part is a Self-service CRU, and ″2″ means that the part is an Optional-service CRU.
Item # 6136 FRUs FRU # CRU 3 Hard disk drive, SATA 1TB 7200RPM/3Gb/8MB (models) 45C5973 1 4 System fan assembly (all models) 43N9655 2 ™ 5 Microprocessor, Core 2 Duo E4600 Processor 2.40GHz 800MHz FSB 2M L2 M-0 Stepping Level, Mainstream/Value FMB (models) 45C5282 2 5 Microprocessor, E4700 Conroe 2.60GHz 800MHz FSB 2M (models) 45R5786 2 5 Microprocessor, E8600 Wolfdale, 3.33GHZ,1333M FSB 6M E-0 (models CTO) 46R8640 2 5 Microprocessor, Core 2 Duo E8500 Processor 3.
Item # FRU # CRU 43N9092 1 FRU # CRU Mech Kit (all models) 43N9569 2 Vertical Stand (all models) 43N9578 1 C2 switch (all models) 43N9579 2 ODD bezel kit (all models) 43N9580 1 Non-ODD bezel kit (all models) 43N9581 1 Card reader bezel kit (all models) 43N9582 1 Non card reader bezel kit (all models) 43N9583 1 Thermal sense cable (all models) 41R8510 2 Power cable for HDD.&.ODD (all models) 43N9136 2 SATA cable - HDD 500 mm (all models) 43N9131 2 Front I_O cable_R (4.
6136 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU French (models A1G) 41A5300 1 French Canadian (models A1F A1G) 41A5301 1 French Canadian (models A1F A1G) 41A5302 1 German (models A1G) 41A5303 1 Greek (models A1G) 41A5304 1 Greek/US (models A1G) 41A5305 1 Hebrew (models A1G) 41A5306 1 Hungarian (models A1G) 41A5307 1 Iceland (models A1G) 41A5308 1 Italian (models A1G) 41A5309 1 Japanese (models A1J) 41A5310 1 Korean (models A1K) 41A5311 1 LA Spanish (m
6136 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Chinese/US (models) 41R0045 1 Czech (models) 41R0046 1 Danish (models) 41R0047 1 Dutch (models) 41R0048 1 French (models) 41R0049 1 French Canadian (models) 41R0050 1 French Canadian (models) 41R0051 1 German (models) 41R0052 1 Greek (models) 41R0053 1 Greek/US (models) 41R0054 1 Hebrew (models) 41R0055 1 Hungarian (models) 41R0056 1 Iceland (models) 41R0057 1 Italian (models) 41R0058 1 Japanese (models) 4
6136 Keyboards (Lenovo Preferred Pro PS/2® - Full Size) FRU # CRU Brazilian Portuguese (models) 41A5044 1 Bulgarian (models) 41A5045 1 Chinese/US (models) 41A5046 1 Czech (models) 41A5047 1 Danish (models) 41A5048 1 Dutch (models) 41A5049 1 French (models) 41A5050 1 French Canadian (models) 41A5051 1 French Canadian (models) 41A5052 1 German (models) 41A5053 1 Greek (models) 41A5054 1 Greek/US (models) 41A5080 1 Hebrew (models) 41A5055 1 Hungarian (models) 41A5056
6136 adapters and miscellaneous FRUs FRU # CRU DP to DVI dongle 200 mm (models CTO) 43N9160 1 IEEE 1394 Firewire adapter (LP) (models CTO) 41D2781 1 Speakers (2-piece) Lenovo Logo (Primary) (models) 41A5331 1 Speakers (2-piece) Lenovo Logo (Secondary) (models) 41A5334 1 Speaker power brick - US, Canada, LA low voltage, ASEAN (models A1U) 89P8571 1 Speaker power brick - LA high voltage (non-APU) (models) 89P8575 1 Speaker power brick - Simplified Chinese, Thailand, EMEA (models A1G A1C)
6136 Microsoft® Windows® XP Home Recovery CDs FRU # CRU US English/UK/Asia Pacific (models) TBD 1 French/Canadian French (models) TBD 1 German (models) TBD 1 Italian (models) TBD 1 Brazilian (models) TBD 1 Spanish/LA (models) TBD 1 Danish (models) TBD 1 Dutch (models) TBD 1 Arabic (models) TBD 1 Swedish (models) TBD 1 Hebrew (models) TBD 1 Finnish (models) TBD 1 Norwegian (models) TBD 1 Polish (models) TBD 1 Portuguese (models) TBD 1 Russian (models) TBD 1
6136 Windows XP Pro Recovery CDs FRU # CRU Polish (models) 53Y7087 1 Portuguese (models) 53Y7094 1 Russian (models) 53Y7089 1 Russian English (models) 63Y8271 1 Hungarian (models) 53Y7092 1 Czech (models) 53Y7084 1 Turkish (models) 53Y7091 1 Greek (models) 53Y7093 1 Slovakian (models) 53Y7095 1 Japanese (models) 53Y7079 1 Simplified Chinese (models) 53Y7096 1 Taiwan - Traditional Chinese (models) 53Y7097 1 Hong Kong - Traditional Chinese (models) 53Y7098 1 Korean (m
6136 Microsoft Windows Vista® Home Basic 32 Recovery DVDs FRU # CRU Slovenian (models) 53Y7230 1 Russian English (models) 53Y7213 1 Hebrew (models) 53Y7233 1 Arabic localized (models) 53Y7231 1 Slovakian (models) 53Y7237 1 Romanian (models) 53Y7234 1 Serbian-Latin (models) 53Y7236 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7238 1 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7239 1 C&L 3 Bel Lux (English, French, German, Dutch)
6136 Vista Business 32 Recovery DVDs FRU # CRU Slovakian (models A1G) 53Y7179 1 Arabic localized (models A1G) 53Y7173 1 Hebrew (models A1G) 53Y7175 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7180 1 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7181 1 C&L 3 Bel Lux (English, French, German, Dutch) (models) 53Y7182 1 FRU # CRU English (models) TBD 1 Russian English (models) TBD 1 French/Canadian French (models) TBD 1 German (mo
6136 Windows Vista Business 64 Recovery DVDs FRU # CRU Russian English (models) 53Y7250 1 Russian French (models) 53Y7251 1 German (models) 53Y7252 1 Spanish (models) TBD 1 Brazilian Portuguese (models) TBD 1 Italian (models) TBD 1 53Y7253 1 Norwegian (models) TBD 1 Swedish (models) TBD 1 Danish (models) TBD 1 Dutch (models) TBD 1 Czech (models) TBD 1 Finnish (models) TBD 1 Polish (models) TBD 1 Russian (models) TBD 1 Turkish (models) TBD 1 Hungarian (models
6136 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU TBD 1 Hong Kong (models) 53Y7247 1 Norwegian (models) TBD 1 Korean (models) TBD 1 Slovenian (models) TBD 1 Greek (models) TBD 1 Russian (models) TBD 1 Portuguese (models) TBD 1 Turkish (models) TBD 1 Czech (models) TBD 1 Polish (models) TBD 1 Russian English (models) TBD 1 Arabic localized (models) 53Y7248 1 Hebrew (models) TBD 1 Hungarian (models) TBD 1 Slovakian (models) TBD 1 53Y7249 1 FRU # CRU T
Machine Type 6139 Item # 6139 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91G) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models 91G) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models91G) 40Y9035 1 3 Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB (models91G) 40Y9036 1 3 Hard disk drive, SATA 320GB 7200RPM SATA/8MB (models91G) 87H4891 1 3 Hard disk drive, SATA 500GB 7200RPM/3Gb
Item # 6139 FRUs FRU # CRU 5 Microprocessor, E7200 Wolfdale 2.53GHZ 1066MHZFSB 3MB M-0 (models 91G) 45R8337 2 5 Microprocessor, E7300 Wolfdale 2.66GHZ 1066FSB FSB 3MB M-0 (models 91G) 46R1622 2 5 Microprocessor, E2160 Conroe-L 1.80GHz 800MHz FSB 1M (models91G) 43C1968 2 5 Microprocessor, E2180 Conroe-L 2.00GHz 800MHz FSB 1M (models91G) 45C1773 2 5 Microprocessor, E2200 Conroe-L 2.20GHz 800MHz FSB 1M (models91G) 45C5349 2 5 Microprocessor, E2220 Conroe-L 2.
6139 FRUs FRU # CRU C2 switch (all models) 43N9579 2 ODD bezel kit (all models) 43N9580 1 Non-ODD bezel kit (all models) 43N9581 1 Card reader bezel kit (all models) 43N9582 1 Non card reader bezel kit (all models) 43N9583 1 Thermal sense cable (all models) 41R8510 2 Power cable for HDD.&.ODD (all models) 43N9136 2 SATA cable - HDD 500 mm (all models) 43N9131 2 Front I_O cable_R (4.
6139 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Greek/US (models 91G) 41A5305 1 Hebrew (models 91G) 41A5306 1 Hungarian (models 91G) 41A5307 1 Iceland (models 91G) 41A5308 1 Italian (models 91G) 41A5309 1 Japanese (models 91G) 41A5310 1 Korean (models 91G) 41A5311 1 LA Spanish (models 91G) 41A5312 1 Norwegian (models 91G) 41A5313 1 Polish (models 91G) 41A5314 1 Portuguese (models 91G) 41A5315 1 Romanian (models 91G) 41A5316 1 Romanian (models 91G) 41
6139 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU French Canadian (models 91G) 41R0050 1 French Canadian (models 91G) 41R0051 1 German (models 91G) 41R0052 1 Greek (models 91G) 41R0053 1 Greek/US (models 91G) 41R0054 1 Hebrew (models 91G) 41R0055 1 Hungarian (models 91G) 41R0056 1 Iceland (models 91G) 41R0057 1 Italian (models 91G) 41R0058 1 Japanese (models 91G) 41R0059 1 Korean (models 91G) 41R0060 1 LA Spanish (models 91G) 41R0061 1 Norwegian (models 91G) 41
6139 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Dutch (models 91G) 41A5049 1 French (models 91G) 41A5050 1 French Canadian (models 91G) 41A5051 1 French Canadian (models 91G) 41A5052 1 German (models 91G) 41A5053 1 Greek (models 91G) 41A5054 1 Greek/US (models 91G) 41A5080 1 Hebrew (models 91G) 41A5055 1 Hungarian (models 91G) 41A5056 1 Iceland (models 91G) 41A5057 1 Italian (models 91G) 41A5058 1 Japanese (models 91G) 41A5059 1 Korean (models 91G) 41
6139 adapters and miscellaneous FRUs FRU # CRU Speaker power brick - LA high voltage (non-APU) (models91G) 89P8575 1 Speaker power brick - Simplified Chinese, Thailand, EMEA (models 91G) 89P8581 1 Speaker power brick - Japanese (models 91G) 89P8577 1 Speaker power brick - Brazilian (models 91G) 89P8583 1 Speaker power brick - Argentina (models 91G) 41A4901 1 Speaker power brick - ANZ (models 91G) 89P8579 1 Speaker power brick - Korea (models 91G) 41A4903 1 Speaker power brick - Hong
6139 Windows XP Home Recovery CDs FRU # CRU Brazilian (models 91G) TBD 1 Spanish/LA (models 91G) TBD 1 Danish (models 91G) TBD 1 Dutch (models 91G) TBD 1 Arabic (models 91G) TBD 1 Swedish (models 91G) TBD 1 Hebrew (models 91G) TBD 1 Finnish (models 91G) TBD 1 Norwegian (models 91G) TBD 1 Polish (models 91G) TBD 1 Portuguese (models 91G) TBD 1 Russian (models 91G) TBD 1 Russian English (models 91G) TBD 1 Hungarian (models 91G) TBD 1 Czech (models 91G) TBD 1 Tur
6139 Windows XP Pro Recovery CDs FRU # CRU Hungarian (models 91G) 53Y7092 1 Czech (models 91G) 53Y7084 1 Turkish (models 91G) 53Y7091 1 Greek (models 91G) 53Y7093 1 Slovakian (models 91G) 53Y7095 1 Japanese (models 91G) 53Y7079 1 Simplified Chinese (models 91G) 53Y7096 1 Taiwan - Traditional Chinese (models 91G) 53Y7097 1 Hong Kong - Traditional Chinese (models 91G) 53Y7098 1 Korean (models 91G) 53Y7099 1 Multilingual - English, Dutch, French, German, Italian (models 91G) T
6139 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Slovakian (models 91G) 53Y7237 1 Romanian (models 91G) 53Y7234 1 Serbian-Latin (models 91G) 53Y7236 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91G) 53Y7238 1 C&L 2 Switzerland (English, French, German, Italian) (models 91G) 53Y7239 1 C&L 3 Bel Lux (English, French, German, Dutch) (models91G) 53Y7240 1 FRU # CRU English (models 91G) 53Y7154 1 French/Canadian French (models 91G) 53Y7156 1 German (
6139 Vista Business 32 Recovery DVDs FRU # CRU C&L 2 Switzerland (English, French, German, Italian) (models 91G) 53Y7181 1 C&L 3 Bel Lux (English, French, German, Dutch) (models91G) 53Y7182 1 FRU # CRU English (models 91G) TBD 1 Russian English (models 91G) TBD 1 French/Canadian French (models 91G) TBD 1 German (models 91G) TBD 1 Spanish (models 91G) TBD 1 Brazilian Portuguese (models 91G) TBD 1 Italian (models 91G) TBD 1 Japanese (models 91G) TBD 1 Norwegian (models 91G)
6139 Windows Vista Business 64 Recovery DVDs FRU # CRU Spanish (models 91G) TBD 1 Brazilian Portuguese (models 91G) TBD 1 Italian (models 91G) TBD 1 53Y7253 1 Norwegian (models 91G) TBD 1 Swedish (models 91G) TBD 1 Danish (models 91G) TBD 1 Dutch (models 91G) TBD 1 Czech (models 91G) TBD 1 Finnish (models 91G) TBD 1 Polish (models 91G) TBD 1 Russian (models 91G) TBD 1 Turkish (models 91G) TBD 1 Hungarian (models 91G) TBD 1 Greek (models 91G) TBD 1 Simplified Ch
6139 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU Korean (models 91G) TBD 1 Slovenian (models 91G) TBD 1 Greek (models 91G) TBD 1 Russian (models 91G) TBD 1 Portuguese (models 91G) TBD 1 Turkish (models 91G) TBD 1 Czech (models 91G) TBD 1 Polish (models 91G) TBD 1 Russian English (models 91G) TBD 1 Arabic localized (models 91G) 53Y7248 1 Hebrew (models 91G) TBD 1 Hungarian (models 91G) TBD 1 Slovakian (models 91G) TBD 1 53Y7249 1 FRU # CRU TBD 1 C&L 1 Nor
Machine Type 7187 Item # 7187 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models A4J A5J A8J 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1J A3J A6J A7J ABJ ACJ ADS ADY 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R AFJ AGJ AHJ AJJ AEJ) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models AFJ AGJ AHJ AJJ AEJ) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models A1J A3J A4J A5J A6J A7J A8J ABJ ACJ ADS
Item # 7187 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W C-0 (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 45C7735 2 5 Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W C-0 (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 45C7736 2 5 Microprocessor, Core 2 Duo E8300 Processor 2.
Item # 7187 FRUs FRU # CRU 5 Microprocessor, E5300 Wolfdale 2.6GHz/800FSB 2MB EIST, EM64T, EDB R-0 (models AEJ) 53Y9049 2 5 Microprocessor, E1500 Conroe 2.2GHZ/800FSB 512KB EIST, EM64T, EDB M-0 (models) 53Y9051 2 5 Microprocessor, E5400 Wolfdale 2.
7187 FRUs FRU # CRU MB tray assembly (all models) 43N9661 2 Universal Adapter Bracket 5.25 to 3.
7187 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Thailand (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5324 1 Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5325 1 Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5326 1 UK English (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5327 1 US Euro (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5328 1 Slovenian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A53
7187 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Slovak (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0069 1 Spanish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0070 1 Swedish/Finnish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0071 1 Swiss French/German (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0072 1 Thailand (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0073 1 Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
7187 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Serbian/Cyrillic (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5067 1 Slovak (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5068 1 Spanish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5069 1 Swedish/Finnish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5070 1 Swiss French/German (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5071 1 Thailand (models 91P 91G 91M 91A 91Q 91C 91B 9
7187 adapters and miscellaneous FRUs FRU # CRU Speaker power brick -Taiwan - TC (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A4905 1 Speaker power brick - India, South Africa (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 89P8585 1 Modem phone cable (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 39K5120 1 Thermal grease syringe (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 91P8835 2 AC line cord for AC/DC power adapter - 1.
7187 Windows XP Home Recovery CDs FRU # CRU Danish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Dutch (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Arabic (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Swedish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Hebrew (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Finnish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Norwegian (models 91P 91G 91M 91A 91Q 91C 91B 91H
7187 Windows XP Pro Recovery CDs FRU # CRU Czech (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7084 1 Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7091 1 Greek (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7093 1 Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7095 1 Japanese (models A3J A7J ABJ 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R AFJ AHJ AEJ) 53Y7079 1 Simplified Chinese (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
7187 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Hebrew (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7233 1 Arabic localized (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7231 1 Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7237 1 Romanian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7234 1 Serbian-Latin (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7236 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (mod
7187 Vista Business 32 Recovery DVDs FRU # CRU Ukrainian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7179 1 Arabic localized (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7173 1 Hebrew (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7175 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7180 1 C&L 2 Switzerland (English, Fre
7187 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Ukrainian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 FRU # CRU Russian English (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7250 1 Russian French (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7251 1 German (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7252 1 Spanish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91
7187 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU Danish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Swedish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Finland (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Dutch (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Traditional Chinese (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Hong Kong (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7247 1 Norwegian (models 9
Machine Type 7345 Item # 7345 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A3J A4J A5J A2J A1J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models A3J A4J A5J A1J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K
Item # 7345 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W C-0 (models A4J A5J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 45C7735 2 5 Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W C-0 (models A3J A2J A1J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 45C7736 2 5 Microprocessor, Core 2 Duo E8300 Processor 2.
Item # 7345 FRUs FRU # CRU 5 Microprocessor, E7400 Wolfdale 2.8GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0 (models) 53Y6653 2 5 Microprocessor, E5300 Wolfdale 2.6GHz/800FSB 2MB EIST, EM64T, EDB R-0 (models) 53Y9049 2 5 Microprocessor, E1500 Conroe 2.2GHZ/800FSB 512KB EIST, EM64T, EDB M-0 (models) 53Y9051 2 5 Microprocessor, E5400 Wolfdale 2.
7345 FRUs FRU # CRU IO shielding assembly (all models) 43N9660 2 MB tray assembly (all models) 43N9661 2 Universal Adapter Bracket 5.25 to 3.
7345 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Russian/Cyrillic (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5318 1 Serbian/Cyrillic (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5319 1 Slovak (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5320 1 Spanish (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5321 1 Swedish/Finnish (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91
7345 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Hungarian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0056 1 Iceland (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0057 1 Italian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0058 1 Japanese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0059 1 Korean (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0060 1
7345 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Dutch (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5049 1 French (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5050 1 French Canadian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5051 1 French Canadian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5052 1 German (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K
7345 adapters and miscellaneous FRUs FRU # CRU DP to DVI dongle 200 mm (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 43N9160 1 IEEE 1394 Firewire adapter (LP) (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41D2781 1 Speakers (2-piece) Lenovo Logo (Primary) (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5331 1 Speakers (2-piece) Lenovo Logo (Secondary) (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A533
7345 Power Cords (Primary) FRU # CRU Line Cord - Y model - Argentina (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 42T5102 1 Line Cord - Brazil (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 42T5177 1 Line Cord - German (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 42T5114 1 Line Cord - UK (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 42T5120 1 Line Cord - Denmark (models 91S 91P 91L 91D 91Y 91G 91M 91A
7345 Windows XP Home Recovery CDs FRU # CRU Norwegian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Polish (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Portuguese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Russian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Russian English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Hungarian (models 91S 9
7345 Windows XP Pro Recovery CDs FRU # CRU Greek (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7093 1 Slovakian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7095 1 Japanese (models A3J A4J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7079 1 Simplified Chinese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7096 1 Taiwan - Traditional Chinese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 9
7345 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7230 1 Russian English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7213 1 Hebrew (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7233 1 Arabic localized (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7231 1 Slovakian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K
7345 Vista Business 32 Recovery DVDs FRU # CRU Korea (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7171 1 Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7172 1 Russian English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7155 1 Romanian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7176 1 TBD 1 53Y7178 1 Ukrainian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K
7345 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Simplified Chinese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Traditional Chinese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Hong Kong (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Korean (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TB
7345 Windows Vista Business 64 Recovery DVDs FRU # CRU Korean (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Portuguese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Arabic (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Hebrew (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) TBD 1 Slovakian (models 91S
7345 Windows Vista Ultimate 32 Recovery DVDs C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 7345 Windows Vista Starter 32 Recovery DVDs English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 164 Hardware Maintenance Manual FRU # CRU 53Y7249 1 FRU # CRU TBD 1
Machine Type 7348 Item # 7348 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models A1G) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models 91G 91M 91A 91Q 91C 91B 91H 91V) 40Y9035 1 3 Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 4
Item # 7348 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) 45C7736 2 5 Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) 45C7737 2 5 Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) 45C7738 2 5 Microprocessor, E8190 Wolfdale 2.
Item # 7348 FRUs FRU # CRU 5 Microprocessor, E5400 Wolfdale 2.
7348 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU US English (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5289 1 Arabic (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5290 1 Arabic/French (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5291 1 Belgian/French (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5292 1 Belgian English (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5293 1 Brazilian Portuguese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5294 1 Bulgarian (mode
7348 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Arabic (New) (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 45J4880 1 Lithuanian (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 45J4896 1 FRU # CRU US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0038 1 Arabic (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0039 1 Arabic/French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0040 1 Belgian/French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0041 1 Belgian/English (models 91G
7348 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Turkish (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0075 1 UK English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0076 1 US Euro (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0077 1 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0078 1 FRU # CRU US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5039 1 Arabic (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5040 1 Arabic/French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A50
7348 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Turkish (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5073 1 Turkish (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5074 1 UK English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5075 1 US Euro (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5076 1 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5077 1 FRU# CRU Optical wheel mouse (400 DPI), USB - red wheel (Primary) (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41U3013 1 Opt
7348 Power Cords (Primary) FRU # CRU Line Cord - Y model - Argentina (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5102 1 Line Cord - Brazil (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5177 1 Line Cord - German (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5114 1 Line Cord - UK (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5120 1 Line Cord - Denmark (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5126 1 Line Cord - Switzerland (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5129 1 Line Co
7348 Windows XP Home Recovery CDs FRU # CRU Hong Kong - Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 FRU # CRU US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7073 1 French/Canadian French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7074 1 German (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7075 1 Italian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7078 1 Brazilian (models 91G 91M 91A 91Q 91C 91B 91H 91V
7348 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Brazilian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7217 1 Italian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y9470 1 Japanese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7225 1 Norwegian (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Swedish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7232 1 Czech (models 91G 91M 91A 91
7348 Vista Business 32 Recovery DVDs FRU # CRU Swedish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7174 1 Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7161 1 Finnish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Polish (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7162 1 Russian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7163 1 Turkish (models 91G 91M 91A 91Q 91C 91B 91H 91
7348 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Finnish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Polish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Russian (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Turkish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Hungarian (models 91G 91M 91A 91Q 91C 91B 91H 91V)
7348 Windows Vista Business 64 Recovery DVDs FRU # CRU TBD 1 Simplified Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7254 1 Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Hong Kong (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Portuguese (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Arabic (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Hebrew (
7348 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7249 1 7348 Windows Vista Starter 32 Recovery DVDs FRU # CRU TBD 1 English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 178 Hardware Maintenance Manual
Machine Type 7356 Item # 7356 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1G) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models A1G) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models 91G 91M 91A 91Q 91C 91B 91H 91V) 40Y9035 1 3 Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 40Y9036 1 3 Hard disk drive, S
Item # 7356 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) 45C7737 2 5 Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) 45C7738 2 5 Microprocessor, E8190 Wolfdale 2.66GHz 1333MHz FSB 6M C-0 - NON VT/Vpro (models 91G 91M 91A 91Q 91C 91B 91H 91V) 45R2568 2 5 Microprocessor, E7200 Wolfdale 2.
Item # 7356 FRUs FRU # CRU 7 Memory module, 512 MB PC3-8500 1066MHz DDR3 SoDIMM (models 91G 91M 91A 91Q 91C 91B 91H 91V) 46R3324 1 7 Memory module, 1GB PC3-8500 1066MHz DDR3 SoDIMM (models 91G 91M 91A 91Q 91C 91B 91H 91V) 46R3325 1 7 Memory module, 2GB PC3-8500 1066MHz DDR3 SoDIMM (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 46R3326 1 8 System board, GA Intel Q45 (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 64Y3057 N 8 System board, 504AT - Swallow (updated V1.
7356 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Arabic (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5290 1 Arabic/French (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5291 1 Belgian/French (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5292 1 Belgian English (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5293 1 Brazilian Portuguese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5294 1 Bulgarian (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5295 1 Chinese/US (mode
7356 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU 45J4896 1 FRU # CRU US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0038 1 Arabic (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0039 1 Arabic/French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0040 1 Belgian/French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0041 1 Belgian/English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0042 1 Brazilian Portuguese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0043 1 Bulgarian (
7356 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU UK English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0076 1 US Euro (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0077 1 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0078 1 FRU # CRU US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5039 1 Arabic (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5040 1 Arabic/French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5041 1 Belgian/French (models 91G 91M 91A 91Q 91C 91B 91H 91V)
7356 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Turkish (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5074 1 UK English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5075 1 US Euro (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5076 1 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5077 1 FRU# CRU Optical wheel mouse (400 DPI), USB - red wheel (Primary) (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41U3013 1 Optical wheel mouse (400 DPI), USB - red wheel (Secondary) (model
7356 Power Cords (Primary) FRU # CRU Line Cord - Y model - Argentina (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5102 1 Line Cord - Brazil (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5177 1 Line Cord - German (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5114 1 Line Cord - UK (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5120 1 Line Cord - Denmark (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5126 1 Line Cord - Switzerland (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5129 1 Line Co
7356 Windows XP Home Recovery CDs FRU # CRU Hong Kong - Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 FRU # CRU US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7073 1 French/Canadian French (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7074 1 German (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7075 1 Italian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7078 1 Brazilian (models 91G 91M 91A 91Q 91C 91B 91H 91V
7356 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Brazilian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7217 1 Italian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y9470 1 Japanese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7225 1 Norwegian (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Swedish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7232 1 Czech (models 91G 91M 91A 91
7356 Vista Business 32 Recovery DVDs FRU # CRU Swedish (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Danish (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Dutch (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7174 1 Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7161 1 Finnish (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Polish (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7162 1 Russian (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7163 1 Turkish (models A1G 91
7356 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Finnish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Polish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Russian (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Turkish (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Hungarian (models 91G 91M 91A 91Q 91C 91B 91H 91V)
7356 Windows Vista Business 64 Recovery DVDs FRU # CRU TBD 1 Simplified Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7254 1 Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Hong Kong (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Portuguese (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Arabic (models 91G 91M 91A 91Q 91C 91B 91H 91V) TBD 1 Hebrew (
7356 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7249 1 7356 Windows Vista Starter 32 Recovery DVDs FRU # CRU TBD 1 English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 192 Hardware Maintenance Manual
Machine Type 7359 Item # 7359 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models A6U A6F A6M A6A A6Q A6T A6H A6K AKM AKA AKQ AKT AKK ANM ANA ANQ ANT ANK ADU ADF AEU AEF AHV A1G A7S A7P A7Y 91C B1U B1F B3U B3F B5U B5F) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A5H A8M A8A A8Q A8T A8K A9M A9A A9Q A9T A9K AJM AJA AJQ AJT AJK ALM ALA ALQ ALT ALK AMM AMA AQM AQA ABU ABF AFU AFF AGU AGF ACG A2G A3G A4G ABU ABF 91C AVM AVA AVQ AVT AVK ATM ATA AUM AUA AUQ AUT AUK ARM ARA B7
Item # 7359 FRUs FRU # CRU 4 System fan assembly (all models) 43N9655 2 5 Microprocessor, Core 2 Duo E4600 Processor 2.40GHz 800MHz FSB 2M L2 M-0 Stepping Level, Mainstream/Value FMB (models 91C) 45C5282 2 5 Microprocessor, E4700 Conroe 2.60GHz 800MHz FSB 2M (models 91C) 45R5786 2 5 Microprocessor, E8600 Wolfdale, 3.33GHZ,1333M FSB 6M E-0 (models 91C) 46R8640 2 5 Microprocessor, Core 2 Duo E8500 Processor 3.
Item # 7359 FRUs FRU # CRU 5 Microprocessor, E7400 Wolfdale 2.8GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0 (models ATM ATA AUM AUA AUQ AUT AUK AWG B1U B1F B2U B2F B6U B6F B6S B6P B6L B6D B6Y B6G B6M B6A B6Q B6T B6C B6B B6H B6V B6K B6R B6E B6J) 53Y6653 2 5 Microprocessor, E5300 Wolfdale 2.6GHz/800FSB 2MB EIST, EM64T, EDB R-0 (models ARM ARA B7M B7A B7Q B7T B7K B5U B5F B8U B8F) 53Y9049 2 5 Microprocessor, E1500 Conroe 2.
7359 FRUs FRU # CRU USB cable (all models) 42Y8006 2 eSATA cable (all models) 43N9143 2 PS2 cable (150 mm) (all models) 43N9149 2 SATA cable - Optical 370 mm (all models) 43N9134 2 Parallel to Parallel Dongle Cable_210mm_R (all models) 45J9520 2 Access cover assembly (all models) 43N9656 2 Base cover assembly (all models) 43N9657 2 Front bezel assembly (all models) 43N9658 2 HDD tray assembly (all models) 43N9659 2 IO shielding assembly (all models) 43N9660 2 MB tray assembl
7359 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Japanese (models 91C B6J) 41A5310 1 Korean (models A6K A8K A9K AJK AKK ALK ANK 91C AVK AUK B7K B6K) 41A5311 1 LA Spanish (models A7S A7Y 91C B6S B6D B6Y) 41A5312 1 Norwegian (models ACG A1G A2G A3G A4G 91C AWG B6G) 41A5313 1 Polish (models ACG A1G A2G A3G A4G 91C AWG B6G) 41A5314 1 Portuguese (models ACG A1G A2G A3G A4G 91C AWG B6G) 41A5315 1 Romanian (models ACG A1G A2G A3G A4G 91C AWG B6G) 41A5316 1 Romanian (models
7359 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Hebrew (models 91C) 41R0055 1 Hungarian (models 91C) 41R0056 1 Iceland (models 91C) 41R0057 1 Italian (models 91C) 41R0058 1 Japanese (models 91C) 41R0059 1 Korean (models 91C) 41R0060 1 LA Spanish (models 91C) 41R0061 1 Norwegian (models 91C) 41R0062 1 Polish (models 91C) 41R0063 1 Portuguese (models 91C) 41R0064 1 Romanian (models 91C) 41R0065 1 Romanian (models 91C) 41R0066 1 Russian/Cyrillic (models 91C) 41R
7359 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Greek (models 91C) 41A5054 1 Greek/US (models 91C) 41A5080 1 Hebrew (models 91C) 41A5055 1 Hungarian (models 91C) 41A5056 1 Iceland (models 91C) 41A5057 1 Italian (models 91C) 41A5058 1 Japanese (models 91C) 41A5059 1 Korean (models 91C) 41A5060 1 LA Spanish (models 91C) 41A5061 1 Norwegian (models 91C) 41A5062 1 Polish (models 91C) 41A5063 1 Portuguese (models 91C) 41A5064 1 Romanian (models 91C) 41A506
7359 adapters and miscellaneous FRUs FRU # CRU DP to DVI dongle 200 mm (models CTO 91C) 43N9160 1 IEEE 1394 Firewire adapter (LP) (models CTO 91C) 41D2781 1 Speakers (2-piece) Lenovo Logo (Primary) (models 91C) 41A5331 1 Speakers (2-piece) Lenovo Logo (Secondary) (models 91C) 41A5334 1 Speaker power brick - US, Canada, LA low voltage, ASEAN (models A6U ABU ADU AEU AFU AGU ABU 91C) 89P8571 1 Speaker power brick - LA high voltage (non-APU) (models 91C) 89P8575 1 Speaker power brick - Simp
7359 Power Cords (Primary) FRU # CRU Line Cord - South Africa (models A6U A6F A6A A6T A8A A8T A9A A9T AJA AJT AKA AKT ALA ALT AMA ANA ANT AQA ABU ABF ADU ADF AEU AEF AFU AFF AGU AGF A7S A7Y ABU ABF 91C AVM AVA ATM ATA AUM AUA ARM ARA B7M B7A AWG B6G B6M B6A) 42T5141 1 Line Cord - Israel (models ACG A1G A2G A3G A4G 91C AWG B6G) 42T5147 1 Line Cord - China (models ACG A1G A2G A3G A4G 91C B6C) 42T5150 1 Line Cord - Taiwan (models ACG A1G A2G A3G A4G 91C B6V) 42T5156 1 Line Cord - Korea (models A
7359 Windows XP Pro Recovery CDs FRU # CRU US English (models AJM AJA AJQ AMM AMA AQM AQA 91C ATM ATA ARM ARA B1U B2U B3U B4U B5U B8U) 53Y7073 1 French/Canadian French (models 91C B1F B2F B3F B4F B5F B8F) 53Y7074 1 German (models 91C) 53Y7075 1 Italian (models 91C) 53Y7078 1 Brazilian (models 91C) 53Y7077 1 Spanish/LA (models 91C) 53Y7076 1 Danish (models 91C) 53Y7082 1 Dutch (models 91C) 53Y7083 1 Arabic English (models 91C) 53Y7088 1 Swedish (models 91C) 53Y7081 1 Hebrew (
7359 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Swedish (models 91C) TBD 1 Danish (models 91C) TBD 1 Dutch (models 91C) 53Y7232 1 Czech (models 91C) 53Y7219 1 Finnish (models 91C) TBD 1 Polish (models 91C) 53Y7220 1 Russian (models 91C) 53Y7221 1 Turkish (models 91C) 53Y7222 1 Hungarian (models 91C) 53Y7223 1 Greek (models 91C) 53Y7224 1 Portuguese (models 91C) 53Y7235 1 Hong Kong (models 91C) 53Y7228 1 Simplified Chinese (models 91C) 53Y7226 1 Traditional
7359 Vista Business 32 Recovery DVDs FRU # CRU 53Y7161 1 Finnish (models ACG A1G A2G A3G A4G 91C AWG B6G) TBD 1 Polish (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7162 1 Russian (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7163 1 Turkish (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7164 1 Hungarian (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7165 1 Greek (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7166 1 Portuguese (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7177 1 Simplified Chinese
7359 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Russian (models 91C) TBD 1 Turkish (models 91C) TBD 1 Hungarian (models 91C) TBD 1 Greek (models 91C) TBD 1 Simplified Chinese (models 91C) TBD 1 Traditional Chinese (models 91C) TBD 1 Hong Kong (models 91C) TBD 1 Korean (models 91C) TBD 1 Slovenian (models 91C) TBD 1 Hebrew (models 91C) TBD 1 Romanian (models 91C) TBD 1 Bulgarian (models 91C) TBD 1 Croatian (models 91C) TBD 1 Portuguese (models 91C) TBD 1
7359 Windows Vista Business 64 Recovery DVDs FRU # CRU Slovenian (models 91C) TBD 1 Portuguese (models 91C) TBD 1 Arabic (models 91C) TBD 1 Hebrew (models 91C) TBD 1 Slovakian (models 91C) TBD 1 FRU # CRU English (models 91C) 53Y7241 1 Japanese (models 91C) 53Y7246 1 TBD 1 French (models 91C) 53Y7242 1 German (models 91C) 53Y7243 1 Spanish (models 91C) 53Y7244 1 Italian (models 91C) 53Y9471 1 Brazilian Portuguese (models 91C) TBD 1 Danish (models 91C) TBD 1 Swed
Machine Type 7479 Item # 7479 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models A9U A9F A4U A4F A4S A4P A4Y 91C 91B 91H) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A5M A5A A5Q A5T A5K A7M A7A A7Q A7T A7K AEM AEA AFM AFA AFQ AFT AFK AGM AGA AGQ AGT AGK A8U A8F ABU ABF ACU ACF A3U A3F A3S A3P A3L A3D A3Y ADV A1G A2G AHS AHP AHY A6U A6F 91C 91B 91H AJU AJF AKU AKF) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models AJU AJF AKU AKF) 41A9767 1 3 Hard dis
Item # 7479 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W C-0 (models AFM AFA AFQ AFT AFK AGM AGA AGQ AGT AGK A9U A9F ABU ABF ACU ACF A2G CTO 91C 91B 91H AKU AKF) 45C7735 2 5 Microprocessor, Core 2 Duo E8400 Processor 3.
Item # 7479 FRUs FRU # CRU 5 Microprocessor, E5400 Wolfdale 2.
7479 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU US English (models A5M A5A A5Q A7M A7A A7Q AEM AEA AFM AFA AFQ AGM AGA AGQ A8U A9U ABU ACU A3U A3L A1G A2G A4U A6U 91C 91B 91H AJU AKU) 41A5289 1 Arabic (models A1G A2G 91C 91B 91H) 41A5290 1 Arabic/French (models A1G A2G 91C 91B 91H) 41A5291 1 Belgian/French (models A1G A2G 91C 91B 91H) 41A5292 1 Belgian English (models A1G A2G 91C 91B 91H) 41A5293 1 Brazilian Portuguese (models A3P A4P AHP 91C 91B 91H) 41A5294 1 Bulgari
7479 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU US Euro (models A1G A2G 91C 91B 91H) 41A5328 1 Slovenian (models A1G A2G 91C 91B 91H) 41A5329 1 Arabic (New) (models A1G A2G 91C 91B 91H) 45J4880 1 Lithuanian (models A1G A2G 91C 91B 91H) 45J4896 1 FRU # CRU US English (models 91C 91B 91H) 41R0038 1 Arabic (models 91C 91B 91H) 41R0039 1 Arabic/French (models 91C 91B 91H) 41R0040 1 Belgian/French (models 91C 91B 91H) 41R0041 1 Belgian/English (models 91C 91B 91H)
7479 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Thailand (models 91C 91B 91H) 41R0073 1 Turkish (models 91C 91B 91H) 41R0074 1 Turkish (models 91C 91B 91H) 41R0075 1 UK English (models 91C 91B 91H) 41R0076 1 US Euro (models 91C 91B 91H) 41R0077 1 Slovenian (models 91C 91B 91H) 41R0078 1 FRU # CRU US English (models 91C 91B 91H) 41A5039 1 Arabic (models 91C 91B 91H) 41A5040 1 Arabic/French (models 91C 91B 91H) 41A5041 1 Belgian/French (models 91C 91B 91H) 41A5042 1
7479 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Swiss French/German (models 91C 91B 91H) 41A5071 1 Thailand (models 91C 91B 91H) 41A5072 1 Turkish (models 91C 91B 91H) 41A5073 1 Turkish (models 91C 91B 91H) 41A5074 1 UK English (models 91C 91B 91H) 41A5075 1 US Euro (models 91C 91B 91H) 41A5076 1 Slovenian (models 91C 91B 91H) 41A5077 1 7479 mice FRU# CRU Optical wheel mouse (400 DPI), USB - red wheel (Primary) (models A5M A5A A5Q A5T A5K A7M A7A A7Q A7T A7K AEM A
7479 Power Cords (Primary) FRU # CRU Line Cord - US/Canada (models A5A A5T A7A A7T AEA AFA AFT AGA AGT A8U A8F A9U A9F ABU ABF ACU ACF A3U A3F A3S A3L A3Y A4U A4F A4S A4Y AHS AHY A6U A6F 91C 91B 91H AJU AJF AKU AKF) 42T5089 1 Line Cord - Japan (models 91C 91B 91H) 42T5096 1 Line Cord - Y model - Argentina (models 91C 91B 91H) 42T5102 1 Line Cord - Brazil (models A3P A4P AHP 91C 91B 91H) 42T5177 1 Line Cord - German (models 91C 91B 91H) 42T5114 1 Line Cord - UK (models 91C 91B 91H) 42T5120
7479 Windows XP Home Recovery CDs FRU # CRU Russian English (models 91C 91B 91H) TBD 1 Hungarian (models 91C 91B 91H) TBD 1 Czech (models 91C 91B 91H) TBD 1 Turkish (models 91C 91B 91H) TBD 1 Greek (models 91C 91B 91H) TBD 1 Japanese (models 91C 91B 91H) TBD 1 Simplified Chinese (models 91C 91B 91H) TBD 1 Taiwan - Traditional Chinese (models 91C 91B 91H) TBD 1 Hong Kong - Traditional Chinese (models 91C 91B 91H) TBD 1 Korean (models 91C 91B 91H) TBD 1 FRU # CRU US English
7479 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU US English (models 91C 91B 91H) 53Y7212 1 French/Canadian French (models 91C 91B 91H) 53Y7214 1 German (models 91C 91B 91H) 53Y7215 1 Spanish/LA (models 91C 91B 91H) 53Y7216 1 Brazilian (models 91C 91B 91H) 53Y7217 1 Italian (models 91C 91B 91H) 53Y9470 1 Japanese (models 91C 91B 91H) 53Y7225 1 Norwegian (models 91C 91B 91H) TBD 1 Swedish (models 91C 91B 91H) TBD 1 Danish (models 91C 91B 91H) TBD 1 Dutch (models 91C 91
7479 Vista Business 32 Recovery DVDs FRU # CRU Spanish (models A1G A2G 91C 91B 91H) 53Y7158 1 Brazilian Portuguese (models A3P A4P 91C 91B 91H) 53Y7159 1 Italian (models A1G A2G 91C 91B 91H) 53Y9468 1 Japanese (models 91C 91B 91H) 53Y7167 1 Norwegian (models A1G A2G 91C 91B 91H) TBD 1 Swedish (models A1G A2G 91C 91B 91H) TBD 1 Danish (models A1G A2G 91C 91B 91H) TBD 1 Dutch (models A1G A2G 91C 91B 91H) 53Y7174 1 Czech (models 91C 91B 91H) 53Y7161 1 Finnish (models A1G A2G 91C 9
7479 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Japanese (models 91C 91B 91H) TBD 1 Norwegian (models 91C 91B 91H) TBD 1 Swedish (models 91C 91B 91H) TBD 1 Danish (models 91C 91B 91H) TBD 1 Dutch (models 91C 91B 91H) TBD 1 Czech (models 91C 91B 91H) TBD 1 Finnish (models 91C 91B 91H) TBD 1 Polish (models 91C 91B 91H) TBD 1 Russian (models 91C 91B 91H) TBD 1 Turkish (models 91C 91B 91H) TBD 1 Hungarian (models 91C 91B 91H) TBD 1 Greek (models 91C 91B 91H) TBD
7479 Windows Vista Business 64 Recovery DVDs FRU # CRU Russian (models 91C 91B 91H) TBD 1 Turkish (models 91C 91B 91H) TBD 1 Hungarian (models 91C 91B 91H) TBD 1 Greek (models 91C 91B 91H) TBD 1 Simplified Chinese (models 91C 91B 91H) 53Y7254 1 Traditional Chinese (models 91C 91B 91H) TBD 1 Hong Kong (models 91C 91B 91H) TBD 1 Korean (models 91C 91B 91H) TBD 1 Slovenian (models 91C 91B 91H) TBD 1 Portuguese (models 91C 91B 91H) TBD 1 Arabic (models 91C 91B 91H) TBD 1 Hebr
7479 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU Hungarian (models 91C 91B 91H) TBD 1 Slovakian (models 91C 91B 91H) TBD 1 53Y7249 1 FRU # CRU TBD 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91C 91B 91H) 7479 Windows Vista Starter 32 Recovery DVDs English (models 91C 91B 91H) 220 Hardware Maintenance Manual
Machine Type 7626 Item # 7626 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C
Item # 7626 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45C7735 2 5 Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45C7736 2 5 Microprocessor, Core 2 Duo E8300 Processor 2.
Item # 7626 FRUs FRU # CRU 5 Microprocessor, Q9550 Yorkfield 2.83GHz 1333FSB 12MB VT, TXT E-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 46R8646 2 5 Microprocessor, Q8200 Yorkfield 2.33GHZ 1333FSB 4MB R-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y3946 2 5 Microprocessor, E7500 Wolfdale 2.93GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0 (models) 53Y6654 2 5 Microprocessor, E7400 Wolfdale 2.
7626 FRUs FRU # CRU SATA cable - Optical 370 mm (all models) 43N9134 2 Parallel to Parallel Dongle Cable_210mm_R (all models) 45J9520 2 Access cover assembly (all models) 43N9656 2 Base cover assembly (all models) 43N9657 2 Front bezel assembly (all models) 43N9658 2 HDD tray assembly (all models) 43N9659 2 IO shielding assembly (all models) 43N9660 2 MB tray assembly (all models) 43N9661 2 Universal Adapter Bracket 5.25 to 3.
7626 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5306 1 Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5307 1 Iceland (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5308 1 Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5309 1 Ja
7626 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Arabic (New) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45J4880 1 Lithuanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45J4896 1 FRU # CRU US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0038 1 Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E
7626 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0059 1 Korean (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0060 1 LA Spanish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0061 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0062 1 Polish
7626 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Belgian/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5042 1 Belgian/English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5043 1 Brazilian Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5044 1 Bulgarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K
7626 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Romanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5065 1 Russian/Cyrillic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5066 1 Serbian/Cyrillic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5067 1 Slovak (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
7626 adapters and miscellaneous FRUs FRU # CRU Speaker power brick - Simplified Chinese, Thailand, EMEA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8581 1 Speaker power brick - Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8577 1 Speaker power brick - Brazilian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8583 1 Speaker power brick - Argentina (mod
7626 Power Cords (Primary) FRU # CRU Line Cord - Italy (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5132 1 Line Cord - Australia / New Zealand (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5135 1 Line Cord - South Africa (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5141 1 Line Cord - Israel (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H
7626 Windows XP Home Recovery CDs FRU # CRU Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Czech (models 91U 91F 91S 91
7626 Windows XP Pro Recovery CDs FRU # CRU Finnish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7085 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7080 1 Polish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7087 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7094 1 Russian (models 91U 91
7626 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y9470 1 Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7225 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Danish (models 91
7626 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Serbian-Latin (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7236 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7238 1 C&L 2 Switzerland (English, French, German, Italian) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7239 1 C&L 3 Bel Lux (Eng
7626 Vista Business 32 Recovery DVDs FRU # CRU Simplified Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7168 1 Traditional Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7169 1 Hong Kong (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7170 1 Korea (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7171 1
7626 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Danish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Dutch (models 91U 91F 91
7626 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Slovakian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 7626 Windows Vista Business 64 Recovery DVDs FRU # CRU Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7250 1 Russian French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7251 1 German (models 91U 91F 91S 91P 91L 91D 91Y 91G 91
7626 Windows Vista Business 64 Recovery DVDs FRU # CRU Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Slovakian (models 91U 91F 9
7626 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Turkish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Czech (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Polish (models 91U 91F 91S 91
Machine Type 7629 Item # 7629 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 9
Item # 7629 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45C7735 2 5 Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45C7736 2 5 Microprocessor, Core 2 Duo E8300 Processor 2.
Item # 7629 FRUs FRU # CRU 5 Microprocessor, Q9550 Yorkfield 2.83GHz 1333FSB 12MB VT, TXT E-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 46R8646 2 5 Microprocessor, Q8200 Yorkfield 2.33GHZ 1333FSB 4MB R-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y3946 2 5 Microprocessor, E7500 Wolfdale 2.93GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0 (models) 53Y6654 2 5 Microprocessor, E7400 Wolfdale 2.
7629 FRUs FRU # CRU SATA cable - Optical 370 mm (all models) 43N9134 2 Parallel to Parallel Dongle Cable_210mm_R (all models) 45J9520 2 Access cover assembly (all models) 43N9656 2 Base cover assembly (all models) 43N9657 2 Front bezel assembly (all models) 43N9658 2 HDD tray assembly (all models) 43N9659 2 IO shielding assembly (all models) 43N9660 2 MB tray assembly (all models) 43N9661 2 Universal Adapter Bracket 5.25 to 3.
7629 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5306 1 Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5307 1 Iceland (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5308 1 Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5309 1 Ja
7629 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Arabic (New) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45J4880 1 Lithuanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45J4896 1 FRU # CRU US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0038 1 Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E
7629 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0059 1 Korean (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0060 1 LA Spanish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0061 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0062 1 Polish
7629 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Belgian/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5042 1 Belgian/English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5043 1 Brazilian Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5044 1 Bulgarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K
7629 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Romanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5065 1 Russian/Cyrillic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5066 1 Serbian/Cyrillic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5067 1 Slovak (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
7629 adapters and miscellaneous FRUs FRU # CRU Speaker power brick - Simplified Chinese, Thailand, EMEA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8581 1 Speaker power brick - Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8577 1 Speaker power brick - Brazilian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8583 1 Speaker power brick - Argentina (mod
7629 Power Cords (Primary) FRU # CRU Line Cord - Italy (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5132 1 Line Cord - Australia / New Zealand (models91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5135 1 Line Cord - South Africa (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5141 1 Line Cord - Israel (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 9
7629 Windows XP Home Recovery CDs FRU # CRU Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Czech (models 91U 91F 91S 91
7629 Windows XP Pro Recovery CDs FRU # CRU Finnish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7085 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7080 1 Polish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7087 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7094 1 Russian (models 91U 91
7629 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y9470 1 Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7225 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Danish (models 91
7629 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Serbian-Latin (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7236 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7238 1 C&L 2 Switzerland (English, French, German, Italian) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7239 1 C&L 3 Bel Lux (Eng
7629 Vista Business 32 Recovery DVDs FRU # CRU Simplified Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7168 1 Traditional Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7169 1 Hong Kong (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7170 1 Korea (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7171 1
7629 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Danish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Dutch (models 91U 91F 91
7629 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Slovakian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 7629 Windows Vista Business 64 Recovery DVDs FRU # CRU Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7250 1 Russian French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7251 1 German (models 91U 91F 91S 91P 91L 91D 91Y 91G 91
7629 Windows Vista Business 64 Recovery DVDs FRU # CRU Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Slovakian (models 91U 91F 9
7629 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Turkish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Czech (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Polish (models 91U 91F 91S 91
Machine Type 7637 Item # 7637 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A
Item # 7637 FRUs FRU # CRU 5 Microprocessor, E8600 Wolfdale, 3.33GHZ,1333M FSB 6M E-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 46R8640 2 5 Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 45C7735 2 5 Microprocessor, Core 2 Duo E8400 Processor 3.
Item # 7637 FRUs FRU # CRU 5 Microprocessor, Q9550 Yorkfield 2.83GHz 1333FSB 12MB VT, TXT E-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 46R8646 2 5 Microprocessor, Q8200 Yorkfield 2.33GHZ 1333FSB 4MB R-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y3946 2 5 Microprocessor, E7500 Wolfdale 2.93GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0 (models) 53Y6654 2 5 Microprocessor, E7400 Wolfdale 2.
7637 FRUs FRU # CRU Serial port cable (all models) 41R6198 2 USB cable (all models) 42Y8006 2 eSATA cable (all models) 43N9143 2 PS2 cable (150 mm) (all models) 43N9149 2 SATA cable - Optical 370 mm (all models) 43N9134 2 Parallel to Parallel Dongle Cable_210mm_R (all models) 45J9520 2 Access cover assembly (all models) 43N9656 2 Base cover assembly (all models) 43N9657 2 Front bezel assembly (all models) 43N9658 2 HDD tray assembly (all models) 43N9659 2 IO shielding assemb
7637 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU German (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5303 1 Greek (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5304 1 Greek/US (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5305 1 Hebrew (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41
7637 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU UK English (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5327 1 US Euro (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5328 1 Slovenian (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5329 1 Arabic (New) (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R
7637 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0056 1 Iceland (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0057 1 Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0058 1 Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41R0059 1 Korean (m
7637 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5039 1 Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5040 1 Arabic/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5041 1 Belgian/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 4
7637 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5062 1 Polish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5063 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5064 1 Romanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5065 1
7637 adapters and miscellaneous FRUs FRU # CRU Speakers (2-piece) Lenovo Logo (Secondary) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 41A5334 1 Speaker power brick - US, Canada, LA low voltage, ASEAN (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8571 1 Speaker power brick - LA high voltage (non-APU) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 89P8575 1 Speaker p
7637 Power Cords (Primary) FRU # CRU Line Cord - UK (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5120 1 Line Cord - Denmark (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5126 1 Line Cord - Switzerland (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 42T5129 1 Line Cord - Italy (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 9
7637 Windows XP Home Recovery CDs FRU # CRU Finnish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Polish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Russian (models 91U 91F 91S 91P 91L 9
7637 Windows XP Pro Recovery CDs FRU # CRU Arabic English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7088 1 Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7081 1 Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7086 1 Finnish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7085 1 Norwegian (models 91
7637 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU German (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7215 1 Spanish/LA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7216 1 Brazilian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7217 1 Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y9470 1 Japanese
7637 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Arabic localized (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7231 1 Slovakian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7237 1 Romanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7234 1 Serbian-Latin (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y723
7637 Vista Business 32 Recovery DVDs FRU # CRU Hungarian (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7165 1 Greek (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7166 1 Portuguese (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7177 1 Simplified Chinese (models A1C 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 53Y7
7637 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Spanish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Brazilian Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Norwegian (m
7637 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Serbian-Latin (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Ukrainian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Slovakian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 7637 Windows
7637 Windows Vista Business 64 Recovery DVDs FRU # CRU Traditional Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Hong Kong (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Korean (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Portuguese (mod
7637 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU Korean (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Greek (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) TBD 1 Portuguese (models 91U 91F 91S
Machine Type 8820 Item # 8820 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models A3U A3F) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A6G A7G A8U A8F A9U A9F ABG ACG ADU ADF AEU AEF) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models A8U A8F A9U A9F ABG ACG ADU ADF AEU AEF) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models A3U A3F A4U A4F A8U A8F A9U A9F AEU AEF) 40Y9035 1 3 Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB (models A1C) 4
Item # 8820 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W C-0 (models) 45C7738 2 5 Microprocessor, E8190 Wolfdale 2.66GHz 1333MHz FSB 6M C-0 - NON VT/Vpro (models) 45R2568 2 5 Microprocessor, E7200 Wolfdale 2.53GHZ 1066MHZFSB 3MB M-0 (models) 45R8337 2 5 Microprocessor, E7300 Wolfdale 2.66GHZ 1066FSB FSB 3MB M-0 (models A6G A7G) 46R1622 2 5 Microprocessor, E2160 Conroe-L 1.
The FRUs listed in the following tables are not illustrated. 8820 FRUs FRU # CRU Mech Kit (all models) 43N9569 2 Vertical Stand (all models) 43N9578 1 C2 switch (all models) 43N9579 2 ODD bezel kit (all models) 43N9580 1 Non-ODD bezel kit (all models) 43N9581 1 Card reader bezel kit (all models) 43N9582 1 Non card reader bezel kit (all models) 43N9583 1 Thermal sense cable (all models) 41R8510 2 Power cable for HDD.&.
8820 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU French Canadian (models A5G A6G A7GA8F A9F ABG ACG ADF AEF) 41A5301 1 French Canadian (models A5G A6G A7GA8F A9F ABG ACG ADF AEF) 41A5302 1 German (models A5G A6G A7GABG ACG) 41A5303 1 Greek (models A5G A6G A7GABG ACG) 41A5304 1 Greek/US (models A5G A6G A7GABG ACG) 41A5305 1 Hebrew (models A5G A6G A7GABG ACG) 41A5306 1 Hungarian (models A5G A6G A7GABG ACG) 41A5307 1 Iceland (models A5G A6G A7GABG ACG) 41A5308 1 Ital
8820 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Czech (models) 41R0046 1 Danish (models) 41R0047 1 Dutch (models) 41R0048 1 French (models) 41R0049 1 French Canadian (models) 41R0050 1 French Canadian (models) 41R0051 1 German (models) 41R0052 1 Greek (models) 41R0053 1 Greek/US (models) 41R0054 1 Hebrew (models) 41R0055 1 Hungarian (models) 41R0056 1 Iceland (models) 41R0057 1 Italian (models) 41R0058 1 Japanese (models) 41R0059 1 Korean (models) 41R00
8820 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Bulgarian (models) 41A5045 1 Chinese/US (models) 41A5046 1 Czech (models) 41A5047 1 Danish (models) 41A5048 1 Dutch (models) 41A5049 1 French (models) 41A5050 1 French Canadian (models) 41A5051 1 French Canadian (models) 41A5052 1 German (models) 41A5053 1 Greek (models) 41A5054 1 Greek/US (models) 41A5080 1 Hebrew (models) 41A5055 1 Hungarian (models) 41A5056 1 Iceland (models) 41A5057 1 Italian (m
8820 adapters and miscellaneous FRUs FRU # CRU DP to DVI dongle 200 mm (models) 43N9160 1 IEEE 1394 Firewire adapter (LP) (models) 41D2781 1 Speakers (2-piece) Lenovo Logo (Primary) (models) 41A5331 1 Speakers (2-piece) Lenovo Logo (Secondary) (models) 41A5334 1 Speaker power brick - US, Canada, LA low voltage, ASEAN (models A3U A4U) 89P8571 1 Speaker power brick - LA high voltage (non-APU) (models) 89P8575 1 Speaker power brick - Simplified Chinese, Thailand, EMEA (models A1C A2C) 89P
8820 Windows XP Home Recovery CDs FRU # CRU US English/UK/Asia Pacific (models) TBD 1 French/Canadian French (models) TBD 1 German (models) TBD 1 Italian (models) TBD 1 Brazilian (models) TBD 1 Spanish/LA (models) TBD 1 Danish (models) TBD 1 Dutch (models) TBD 1 Arabic (models) TBD 1 Swedish (models) TBD 1 Hebrew (models) TBD 1 Finnish (models) TBD 1 Norwegian (models) TBD 1 Polish (models) TBD 1 Portuguese (models) TBD 1 Russian (models) TBD 1 Russian Engl
8820 Windows XP Pro Recovery CDs FRU # CRU Polish (models A6GACG) 53Y7087 1 Portuguese (models A6GACG) 53Y7094 1 Russian (models A6GACG) 53Y7089 1 Russian English (models A6GACG) 63Y8271 1 Hungarian (models A6GACG) 53Y7092 1 Czech (models A6GACG) 53Y7084 1 Turkish (models A6GACG) 53Y7091 1 Greek (models A6GACG) 53Y7093 1 Slovakian (models A6GACG) 53Y7095 1 Japanese (models) 53Y7079 1 Simplified Chinese (models) 53Y7096 1 Taiwan - Traditional Chinese (models) 53Y7097 1
8820 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU Slovenian (models) 53Y7230 1 Russian English (models) 53Y7213 1 Hebrew (models) 53Y7233 1 Arabic localized (models) 53Y7231 1 Slovakian (models) 53Y7237 1 Romanian (models) 53Y7234 1 Serbian-Latin (models) 53Y7236 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7238 1 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7239 1 C&L 3 Bel Lux (English, French, German, Dutch) (models)
8820 Vista Business 32 Recovery DVDs FRU # CRU Slovakian (modelsABG) 53Y7179 1 Arabic localized (modelsABG) 53Y7173 1 Hebrew (modelsABG) 53Y7175 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7180 1 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7181 1 C&L 3 Bel Lux (English, French, German, Dutch) (models) 53Y7182 1 FRU # CRU English (models) TBD 1 Russian English (models) TBD 1 French/Canadian French (models) TBD 1 German (model
8820 Windows Vista Business 64 Recovery DVDs FRU # CRU Russian English (models) 53Y7250 1 Russian French (models) 53Y7251 1 German (models) 53Y7252 1 Spanish (models) TBD 1 Brazilian Portuguese (models) TBD 1 Italian (models) TBD 1 53Y7253 1 Norwegian (models) TBD 1 Swedish (models) TBD 1 Danish (models) TBD 1 Dutch (models) TBD 1 Czech (models) TBD 1 Finnish (models) TBD 1 Polish (models) TBD 1 Russian (models) TBD 1 Turkish (models) TBD 1 Hungarian (models
8820 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU TBD 1 Hong Kong (models) 53Y7247 1 Norwegian (models) TBD 1 Korean (models) TBD 1 Slovenian (models) TBD 1 Greek (models) TBD 1 Russian (models) TBD 1 Portuguese (models) TBD 1 Turkish (models) TBD 1 Czech (models) TBD 1 Polish (models) TBD 1 Russian English (models) TBD 1 Arabic localized (models) 53Y7248 1 Hebrew (models) TBD 1 Hungarian (models) TBD 1 Slovakian (models) TBD 1 53Y7249 1 FRU # CRU T
Machine Type 9961 Item # 9961 FRUs FRU # CRU 1 DVD-ROM 16X Max SATA (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41N3325 1 1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1U A1F 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V A3U A3F) 43C1042 1 2 130W AC/DC Power Adapter WW, Robust, JP (models A3U A3F) 41A9767 1 3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models A1U A1F 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 40Y9035 1 3 Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB
Item # 9961 FRUs FRU # CRU 5 Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W C-0 (models A1U A1F 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 45C7736 2 5 Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W C-0 (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 45C7737 2 5 Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W C-0 (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 45C7738 2 5 Microprocessor, E8190 Wolfdale 2.
Item # 9961 FRUs FRU # CRU 5 Microprocessor, E5400 Wolfdale 2.
9961 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU US English (models A1U 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V A3U) 41A5289 1 Arabic (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5290 1 Arabic/French (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5291 1 Belgian/French (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5292 1 Belgian English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5293 1 Brazilian Portuguese (models 91S 91P 91L 91D 91Y 91G 91C 91B 9
9961 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU Arabic (New) (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 45J4880 1 Lithuanian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 45J4896 1 FRU # CRU US English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0038 1 Arabic (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0039 1 Arabic/French (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0040 1 Belgian/French (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V)
9961 Keyboards (Lenovo Fingerprint Reader USB) FRU # CRU Turkish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0075 1 UK English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0076 1 US Euro (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0077 1 Slovenian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0078 1 FRU # CRU US English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5039 1 Arabic (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5040 1 Arabic/French
9961 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU Turkish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5073 1 Turkish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5074 1 UK English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5075 1 US Euro (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5076 1 Slovenian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5077 1 9961 mice FRU# CRU Optical wheel mouse (400 DPI), USB - red wheel (Primary) (models A1
9961 Power Cords (Primary) FRU # CRU Line Cord - US/Canada (models A1U A1F A2U A2F 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V A3U A3F) 42T5089 1 Line Cord - Japan (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 42T5096 1 Line Cord - Y model - Argentina (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 42T5102 1 Line Cord - Brazil (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 42T5177 1 Line Cord - German (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 42T5114 1 Line Cord - UK (models 91S 9
9961 Windows XP Home Recovery CDs FRU # CRU Greek (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Japanese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Simplified Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Taiwan - Traditional Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Hong Kong - Traditional Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Korean (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 FRU # CRU US
9961 Windows Vista Home Basic 32 Recovery DVDs FRU # CRU US English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7212 1 French/Canadian French (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7214 1 German (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7215 1 Spanish/LA (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7216 1 Brazilian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7217 1 Italian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y9470 1 Japanese (
9961 Vista Business 32 Recovery DVDs FRU # CRU Brazilian Portuguese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7159 1 Italian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y9468 1 Japanese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7167 1 Norwegian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Swedish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Danish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Dutch (models 91S 91P 91L 91D 91Y 91G 9
9961 Windows Vista Home Premium 32 Recovery DVDs FRU # CRU Italian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Japanese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Norwegian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Swedish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Danish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Dutch (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Czech (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V)
9961 Windows Vista Business 64 Recovery DVDs FRU # CRU Polish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Russian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Turkish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Hungarian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Greek (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Simplified Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7254 1 Traditional Chinese (models 91S 91P 91L 91D
9961 Windows Vista Ultimate 32 Recovery DVDs FRU # CRU Hebrew (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Hungarian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 Slovakian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) TBD 1 53Y7249 1 FRU # CRU TBD 1 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 9961 Windows Vista Starter 32 Recovery DVDs English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Chapter
308 Hardware Maintenance Manual
Chapter 10. Additional service information This chapter provides additional information that the service representative might find helpful. Security features Security features in this section include the following: v Passwords v Vital Product Data v Secure Managed Client (some models) Hardware controlled passwords Use the Setup Utility program to set the hardware controlled passwords. For more information about passwords, see “Using passwords” on page 49.
v Sources for obtaining the latest level BIOS available 1. Lenovo support web site: http://www.lenovo.com/support/ 2. Lenovo Customer Support Center 3. Levels 1 and 2 Support To update (flash) the BIOS, see “Updating (flashing) BIOS from a disc.” Updating (flashing) BIOS from a disc This section provides instructions on how to update (flash) BIOS from a disc. System BIOS program updates are available at: http://www.lenovo.com/support To update (flash) BIOS from a disc: 1.
10. The recovery session will take two to three minutes. During this time you will hear a series of beeps. After the update session is completed, there will be no video, the series of beeps will end, and the system will automatically turn off. Remove the disc from the optical drive before the system completely turns off. 11. Repeat steps 2 through 4. 12. Move the jumper back to the standard position (pin 1 and pin 2). 13. Reconnect any cables that were disconnected.
312 Hardware Maintenance Manual
Appendix. Notices Lenovo may not offer the products, services, or features discussed in this document in all countries. Consult your local Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used.
vary significantly. Some measurements may have been made on development-level systems and there is no guarantee that these measurements will be the same on generally available systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment. Television output notice The following notice applies to models that have the factory-installed television-output feature.
Part Number: 53Y6832 Printed in USA (1P) P/N: 53Y6832
