7187 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # CRU
Serbian/Cyrillic (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5067 1
Slovak (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5068 1
Spanish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5069 1
Swedish/Finnish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5070 1
Swiss French/German (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5071 1
Thailand (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5072 1
Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5073 1
Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5074 1
UK English (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5075 1
US Euro (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5076 1
Slovenian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5077 1
7187 mice FRU# CRU
Optical wheel mouse (400 DPI), USB - red wheel (Primary) (models A1J A3J A4J A5J A6J
A7J A8J ABJ ACJ ADS ADY 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R AFJ AGJ
AHJ AJJ AEJ)
41U3013 1
Optical wheel mouse (400 DPI), USB - red wheel (Secondary) (models A1J A3J A4J A5J A6J
A7J A8J ABJ ACJ ADS ADY 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R AFJ AGJ
AHJ AJJ AEJ)
41U3030 1
7187 adapters and miscellaneous FRUs FRU # CRU
DP to DVI dongle 200 mm (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 43N9160 1
IEEE 1394 Firewire adapter (LP) (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K
91R)
41D2781 1
Speakers (2-piece) Lenovo Logo (Primary) (models 91P 91G 91M 91A 91Q 91C 91B 91H
91V 91K 91R)
41A5331 1
Speakers (2-piece) Lenovo Logo (Secondary) (models 91P 91G 91M 91A 91Q 91C 91B 91H
91V 91K 91R)
41A5334 1
Speaker power brick - US, Canada, LA low voltage, ASEAN (models 91P 91G 91M 91A
91Q 91C 91B 91H 91V 91K 91R)
89P8571 1
Speaker power brick - LA high voltage (non-APU) (models 91P 91G 91M 91A 91Q 91C 91B
91H 91V 91K 91R)
89P8575 1
Speaker power brick - Simplified Chinese, Thailand, EMEA (models 91P 91G 91M 91A 91Q
91C 91B 91H 91V 91K 91R)
89P8581 1
Speaker power brick - Japanese (models A1J A3J A4J A5J A6J A7J A8J ABJ ACJ 91P 91G
91M 91A 91Q 91C 91B 91H 91V 91K 91R AFJ AGJ AHJ AJJ AEJ)
89P8577 1
Speaker power brick - Brazilian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K
91R)
89P8583 1
Speaker power brick - Argentina (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K
91R)
41A4901 1
Speaker power brick - ANZ (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 89P8579 1
Speaker power brick - Korea (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A4903 1
Speaker power brick - Hong Kong, EMEA (models 91P 91G 91M 91A 91Q 91C 91B 91H
91V 91K 91R)
89P8573 1
Chapter 9. FRU lists 141
