7626 FRUs FRU # CRU
SATA cable - Optical 370 mm (all models) 43N9134 2
Parallel to Parallel Dongle Cable_210mm_R (all models) 45J9520 2
Access cover assembly (all models) 43N9656 2
Base cover assembly (all models) 43N9657 2
Front bezel assembly (all models) 43N9658 2
HDD tray assembly (all models) 43N9659 2
IO shielding assembly (all models) 43N9660 2
MB tray assembly (all models) 43N9661 2
Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 2
65W Heatsink kit (all models) 43N9427 2
7626 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # CRU
US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H
91V 91K 91R 91E 91J)
41A5289 1
Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5290 1
Arabic/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H
91V 91K 91R 91E 91J)
41A5291 1
Belgian/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B
91H 91V 91K 91R 91E 91J)
41A5292 1
Belgian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B
91H 91V 91K 91R 91E 91J)
41A5293 1
Brazilian Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C
91B 91H 91V 91K 91R 91E 91J)
41A5294 1
Bulgarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5295 1
Chinese/US (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H
91V 91K 91R 91E 91J)
41A5296 1
Czech (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5297 1
Danish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5298 1
Dutch (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5299 1
French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5300 1
French Canadian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B
91H 91V 91K 91R 91E 91J)
41A5301 1
French Canadian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B
91H 91V 91K 91R 91E 91J)
41A5302 1
German (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5303 1
Greek (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K
91R 91E 91J)
41A5304 1
Greek/US (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V
91K 91R 91E 91J)
41A5305 1
