Personal Computer Hardware Maintenance Manual

Machine Type 8820
Item # 8820 FRUs FRU # CRU
1 DVD-ROM 16X Max SATA (models A3U A3F) 41N3325 1
1 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A6G
A7G A8U A8F A9U A9F ABG ACG ADU ADF AEU AEF)
43C1042 1
2 130W AC/DC Power Adapter WW, Robust, JP (models A8U A8F A9U A9F ABG
ACG ADU ADF AEU AEF)
41A9767 1
3 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models A3U A3F A4U A4F
A8U A8F A9U A9F AEU AEF)
40Y9035 1
3 Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB (models A1C) 40Y9036 1
3 Hard disk drive, SATA 320GB 7200RPM SATA/8MB (models A6G A7G ABG ACG
ADU ADF)
87H4891 1
3 Hard disk drive, SATA 500GB 7200RPM/3Gb/s/8MB (models A2C) 41X5582 1
3 Hard disk drive, SATA 1TB 7200RPM/3Gb/8MB (models) 45C5973 1
4 System fan assembly (all models) 43N9655 2
5 Microprocessor, Core 2 Duo E4600 Processor 2.40GHz 800MHz FSB 2M L2 M-0
Stepping Level, Mainstream/Value FMB (models)
45C5282 2
5 Microprocessor, E4700 Conroe 2.60GHz 800MHz FSB 2M (models) 45R5786 2
5 Microprocessor, E8600 Wolfdale, 3.33GHZ,1333M FSB 6M E-0 (models) 46R8640 2
5 Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W
C-0 (models)
45C7735 2
5 Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W
C-0 (models)
45C7736 2
5 Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W
C-0 (models)
45C7737 2
Chapter 9. FRU lists 281
