MachineType9485
Item
#9485FRUsFRU#CRU
1
AMD89W&65W4Pinheatsink(allmodels)
41R64072
2
Microprocessor,Athlon644800+X2(2.50GHz,1ML2,65W)G165nm(models)43C4093
N
2
Microprocessor,Athlon645000+X2(2.60GHz,1ML2,65W)G165nm(models)
41X1427N
2
Microprocessor,Athlon1640B(2.70GHz,512KL2,45W)G265nm(modelsB3HA4U
A4FE4UE4F)
45R6488N
2
Microprocessor,Athlon645200+X2(2.70GHz,1ML2,65W)G165nm(models)45C7502
N
2
Microprocessor,Athlon645400BX2(2.80GHz,1ML2,65W)G265nm(modelsD1H
D6MD6AD6QD6TD6KD7MD7AD7QD7TD7KD8AD8QA5GA1UA1FA1SA1P
A1LA1DA1YA1MA1AA1QA1TA1CA1BA1HA1VA1KA1RF4MF4AF4QF4T
F4KE8UE8FE9UE9FJ1UJ1F)
45R6486N
2
Microprocessor,Athlon645600+X2(2.90GHz,1ML2,89W)G265nm(models)45C7504
N
2
Microprocessor,AthlonBE-2350X2(2.10GHz,1ML2,45W)G265nm(models)43C6166
N
2
Microprocessor,AthlonBE-2400X2(2.30GHz,1ML2,45W)G265nm(models)43C6165
N
2
Microprocessor,Athlon4450BX2(2.30GHz,1ML2,45W)G265nm(modelsH2AH2Q
H2TH3KF8UF8FF9UF9FH1UH1FF7G)
46R3624N
2
Microprocessor,Athlon5000BX2(2.60GHz,1ML2,65W)G265nm(modelsB2HD2M
D2AD2QD2TD3MD3AD3QD3TD5AD5QE2UE2FA6MA6AA6QA6TA6KA7A
A7QB7VA9SA9PA9DA9YB5VF3MF3AF3QF3TE5UE5FE6UE6FE7UE7F)
46R3625N
2
Microprocessor,Athlon5200BX2(2.70GHz,1ML2,65W)G265nm(models)
46R3626N
2
Microprocessor,AthlonLE-1660(2.8GHz,512KL2,45W)G265nm(modelsCTO)
53Y7722N
286ThinkCentreHardwareMaintenanceManual
