Microprocessorandheatsink

FrontUSB2connector

Memoryconnector1

ClearCMOSjumper

Memoryconnector2

FrontUSB1connector

Memoryconnector3

COM2connector

Memoryconnector4

COM1connector

24-pinpowerconnector

CD-INconnector

Thermalsensorconnector

Frontaudioconnector

Diskettedriveconnector

PCIadapterconnectors(2)

Intrusionswitchconnector

PCIExpressx16adapterconnector

SATAconnector

PCIExpressx1adapterconnector

SATAconnectors(3)

Battery

Accessingsystemboardcomponentsanddrives

Attention

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"

intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre

SafetyandWarrantyGuide,goto:http://www.lenovo.com/support

Youmightneedtoremovethedrivebayassemblytoaccesssystemboardcomponentssuchasmemory,

thebattery,andCMOS.

Toaccesssystemboardcomponentsandthedrives:

1.Removethecomputercover.See"Removingthecover"onpage94.

2.Removethefrontbezelbyreleasingthethreetabsandpivotingthebezelforwardtoremovecompletely.

3.Insomemodels,youmighthavetoremovethePCIadaptercardinordertogainaccesstothebattery.

96ThinkCentreHardwareMaintenanceManual
