Replacingthemicroprocessor

CAUTION:

Theheatsinkandmicroprocessormightbeveryhot.Turnoffthecomputerandwait

threetoveminutestoletthecomputercoolbeforeopeningthecomputercover.

Attention

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"

intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre

SafetyandWarrantyGuide,goto:http://www.lenovo.com/support

Thissectionprovidesinformationonhowtoremoveandreplacethemicroprocessor.

Toremoveorreplacethemicroprocessor,dothefollowing:

1.Removethecover.See"Removingthecover"onpage94.

2.Liftthefanductofftheheatsinkfan.

3.Disconnecttheheatsinkandfanassemblycablefromthesystemboard.See"Locatingpartsonthe

systemboard"onpage95.

4.Rotatehandle1toreleasetheheatsinkclampandthendisengagetheclampfromtheplasticretention

bracket.

5.Lifttheheatsinkandfanassemblyoffthesystemboard.Placetheheatsinkonitssidesothatthe

thermalgreasedoesnotcomeincontactwithanything.

Note:Youmighthavetogentlytwisttheheatsinktofreeitfromthemicroprocessor.

6.Toreleasethemicroprocessor2fromthesystemboardsocket,liftthesmallhandle1.

104ThinkCentreHardwareMaintenanceManual
