Item
#9342FRUsFRU#CRU
10
PowerSupply,220Watt80%worldwideandJapan(modelsD4MA4JA5JA6JA7J
A8JA9JB1JB2JB3JB4JB5JB6JB7JB8JA1JD3VA2SA2PA2DA2YA3SA3P
A3DA3YB9CD5JD6JD7JD8JD9JE1JE2JE3JE4JE5JE6JE7J)
41A9670N
10
PowerSupply,280WattTFXActivePFC,worldwideandJapan(modelsD4MA4JA5J
A6JA7JA8JA9JB1JB2JB3JB4JB5JB6JB7JB8JA1JD3VA2SA2PA2DA2YA3S
A3PA3DA3YB9CD5JD6JD7JD8JD9JE1JE2JE3JE4JE5JE6JE7J)
41A9705N
TheFRUslistedinthefollowingtablesarenotillustrated.
9342FRUsFRU#CRU
FrurearIOshieldATX,forRX780,Atlantic(allmodels)
41R6383N
FDDCable(allmodels)
41A71472
Cabel-SATA250mm(RoHS)(allmodels)
43N90122
EMCShield,Blank5.25(allmodels)
41N82712
EMCShield,BlankFDD(allmodels)
41N82732
Cover,RockyS3(allmodels)
41N82042
MechanicalshellkitRockyS4(allmodels)
43N9374N
Bezelkit,RockyS3withoutIBMlogo(allmodels)
41R62382
MiscHardwareKit(allmodels)
41N82092
HDDBracketAsm(plasticandgrommets)(allmodels)
41N82102
HDDFanandbracketasm(allmodels)
41R63252
SpeakerCableAsm,600mmcablelength(allmodels)
41N82172
RearCom2cableIILP(allmodels)
42Y80082
RearUSB2PortsIILP(allmodels)
42Y80062
FootstandASMforACErockyS3(allmodels)
41R48131
InstructionswitchAsm(allmodels)
41R62082
RMAsm,AMD(allmodels)
41R2507N
TempSenseCable(165mm)(allmodels)
43N90792
Cable,MINI,COM2CABLE(ROHS)(allmodels)
41R61982
9342Keyboards(LenovoPreferredProUSB--withouthub)FRU#
CRU
Tier
USBFULL--USEnglish(modelsD4M)
41A52891
USBFULL--Arabic(models)
41A52901
USBFULL--Arabic/French(models)
41A52911
USBFULL--Belgian/French(models)
41A52921
USBFULL--BelgiumEnglish(models)
41A52931
USBFULL--BrazilianPortuguese(modelsA2PA3P)
41A52941
USBFULL--Bulgarian(models)
41A52951
USBFULL--Chinese/US(modelsD3V)
41A52961
USBFULL--Czech(ABB)(models)
41A52971
Chapter10FRUlists211
