9623VistaUltimate32RecoveryCDsFRU#CRU
HongKong(models)
46R81551
ArabicLocalized(models)
46R81561
AthensVistaSP1MUL1P/N'sVU32(ENDKFINOSV)(models)
53Y42391
9623VistaHomePremium64RecoveryCDsFRU#CRU
US(models)
71Y66341
French(models)
71Y66351
9623Win7Professional32FRU#CRU
BrazilianPortuguese(allmodels)
89Y04541
MachineType9624
Item
#9624FRUsFRU#CRU
1
AMD89W&65W4Pinheatsink(ROCKYS)(allmodels)
41R64072
2
Microprocessor,Athlon644800+X2(2.50GHz,1ML2,65W)G165nm(models)43C4093
N
2
Microprocessor,Athlon645000+X2(2.60GHz,1ML2,65W)G165nm(modelsA2G)
41X1427N
2
Microprocessor,Athlon1640B(2.70GHz,512KL2,45W)G265nm(modelsCTO)
45R6488N
2
Microprocessor,Athlon645200+AM2X2(2.7GHzprocessor,65W)steppingG165nm
(models)
45C7502
N
2
Microprocessor,Athlon645400BX2(2.80GHz,1ML2,65W)G265nm(modelsCTO)
45R6486N
2
Microprocessor,Athlon645600+X2(2.90GHz,1ML2,89W)G265nm(models)45C7504
N
2
Microprocessor,AthlonX2BE2350(2.1GHzprocessor,45W,1MBL2)stepingG1
(models)
43C6166
N
2
Microprocessor,AthlonX2BE2400(2.3GHzprocessor,45W,1MBL2)stepingG1
(models)
43C6165
N
2
Microprocessor,Athlon4450BX2(2.30GHz,1ML2,45W)G265nm(models)
46R3624N
Chapter10FRUlists331
