Item
#9935FRUsFRU#CRU
13
Powersupply,ATX280W80%(Robust,WW,JP)(models99GA7HA8VA9VA4VA5V
A6VA2VA3CA1VB1UB1FB2UB2FB3UB3FB4UB4FB5UB5FB6UB6FB7U
B7FD1UD1FD3UD3FD3SD3DD3YD4UD4FD4SD4DD4YD5UD5FD5SD5D
D5YD6UD6FD6SD6DD6Y)
41A96652
13
Powersupply,ATX310W(Robust,WW,JP)(models99GA7HA8VA9VA4VA5V
A6VA2VA3CA1VB1UB1FB2UB2FB3UB3FB4UB4FB5UB5FB6UB6FB7U
B7FD1UD1FD3UD3FD3SD3DD3YD4UD4FD4SD4DD4YD5UD5FD5SD5D
D5YD6UD6FD6SD6DD6Y)
41A97262
13
Powersupply,220W(Robust,WW)(models99GA7HA8VA9VA4VA5VA6VA2V
A3CA1VB1UB1FB2UB2FB3UB3FB4UB4FB5UB5FB6UB6FB7UB7FD1U
D1FD3UD3FD3SD3DD3YD4UD4FD4SD4DD4YD5UD5FD5SD5DD5YD6U
D6FD6SD6DD6Y)
41A9689N
13
Powersupply,220WonlyforJP(models)
41A9697N
13
Powersupply,220W80%(Robust,WW,JP)(models99GA7HA8VA9VA4VA5V
A6VA2VA3CA1VB1UB1FB2UB2FB3UB3FB4UB4FB5UB5FB6UB6FB7U
B7FD1UD1FD3UD3FD3SD3DD3YD4UD4FD4SD4DD4YD5UD5FD5SD5D
D5YD6UD6FD6SD6DD6Y)
41A9670N
13
Powersupply,280WTFX,ActivePFC,(Robust,WW,JP)(models99GA7HA8VA9V
A4VA5VA6VA2VA3CA1VB1UB1FB2UB2FB3UB3FB4UB4FB5UB5FB6U
B6FB7UB7FD1UD1FD3UD3FD3SD3DD3YD4UD4FD4SD4DD4YD5UD5F
D5SD5DD5YD6UD6FD6SD6DD6Y)
41A9705N
TheFRUslistedinthefollowingtablesarenotillustrated.
9935FRUsFRU#CRU
Cover(allmodels)
41N80502
Retainer,CardReader(allmodels)
41R29132
FrontFanAVC(allmodels)
41R47912
HDDTray(allmodels)
41R62912
FDDcable,325mm,(allmodels)
41A71822
Cabel-SATA457mm(RoHS)(allmodels)
43N90132
Cabel-SATA250mm(RoHS)(allmodels)
43N90122
OptionalHDDBracketAsm(allmodels)
41R61062
EMCShield(allmodels)
41N80802
EMCShield(allmodels)
41N80782
RearIOshieldATX,forRX780,Atlantic(allmodels)
41R6383N
IntrusionSwitchAsm(allmodels)
41R61162
TempSensecableforArmstrong(460mm)(allmodels)
41R25092
Blank5.25"Bezel(allmodels)
41N80772
AsmChassisWithoutIBMMarkAtlantic(allmodels)
41R6408
5
ODD/FDD/CardreaderRetainers(allmodels)
43N93512
AMDthermalKIT(allmodels)
41R64072
CableClip,FW-6D(allmodels)
43N94622
414ThinkCentreHardwareMaintenanceManual
