Voltageselectionswitch(some

models)

USBconnectors(2)

Powercordconnector

Microphoneconnector

Standardmouseconnector

Audioline-outconnector

Standardkeyboardconnector

Audioline-inconnector

Digitalvideointerface(DVI)monitor

connector

PCIExpressx1adapterconnector

Parallelconnector

PCIExpressx16graphicsadapterconnector

Videographicsarray(VGA)monitor

connector

PCIadapterconnectors(2)

USBconnectors(4)

Serialconnector(somemodels)

Ethernetconnector

Removingthecover

CAUTION:

Theheatsinkandmicroprocessormightbeveryhot.Turnoffthecomputerandwait

threetoveminutestoletthecomputercoolbeforeopeningthecomputercover.

Thissectionprovidesinstructionsonhowtoremovethecover.

Toremovethecover,dothefollowing:

1.Shutdowntheoperatingsystem,removeanymedia(DVDs,CDs,ortapes)fromthedrives,andturnoff

allattacheddevices.

2.Unplugallpowercordsfromelectricaloutlets.
