5
PCIadaptercard
10
Powersupply
Locatingpartsonthesystemboard
1
4-pinpowerconnector
15
Powerfanconnector
2
Systemfanconnector
16
Frontpanelconnector
3
Microprocessorfanconnector
17
Internalspeakerconnector
4
Microprocessorandheatsink
18
FrontUSBconnector2
5
Memoryconnector1
19
ClearCMOS/Recoveryjumper
6
Memoryconnector2
20
FrontUSBconnector1
7
Memoryconnector3
21
Serial(COM2)connector
8
Memoryconnector4
22
Serial(COMl)connector
9
24-pinpowerconnector
23
CD-INconnector
10
Thermalsensorconnector
24
Frontaudioconnector
11
Diskettedriveconnector
25
PCIadapterconnectors(2)
12
Coverpresence(Intrusion)switchconnector
26
PCIExpressx16graphicsadapterconnector
13
SATAconnector
27
PCIExpressx1adapterconnector
14
SATAconnectors(3)
28
Battery
Removingandreplacingthefrontbezel
Thissectionprovidesinformationonhowtoremoveandreplacethefrontbezel.
Toinstallorreplacethefrontbezel:
Chapter8ReplacingFRUs(Types7061,7090,9353,9421,9485,9623,9625,9705,9786,9795,9935,9946,9953)71
