3.Removethememorymodulebeingreplacedbyopeningtheretainingclipsasshown.

4.Positionthenewmemorymoduleoverthememoryconnector.Makesurethenotch1

onthememoryalignscorrectlywiththeconnectorkey2onthesystemboard.Push

thememorymodulestraightdownintotheconnectoruntiltheretainingclipsclose.

5.Goto"CompletingtheFRUreplacement"onpage91.

ReplacingaPCIadaptercard

Attention

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"

intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre

SafetyandWarrantyGuide,goto:http://www.lenovo.com/support

ThissectionprovidesinformationonhowtoremoveandreplaceaPCIadaptercard.

ToremoveorreplaceaPCIadaptercard,dothefollowing:

1.Removethecomputercover.See"Removingthecover"onpage68.

2.Attherearofthecomputer,pressthereleasebutton1toopentheadapterlatch2andremovethe

slotcover.

80ThinkCentreHardwareMaintenanceManual
