6.Routethefancabletothesystemboardandconnectthecabletothesystemboard.See"Locating

partsonthesystemboard"onpage71.

7.Goto"CompletingtheFRUreplacement"onpage91.

Replacingthefrontfanassembly

Attention

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"

intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre

SafetyandWarrantyGuide,goto:http://www.lenovo.com/support

Thissectionprovidesinformationonhowtoremoveandreplacethefrontfanassembly.

Toremoveorreplacethefrontfanassembly,dothefollowing:

1.Removethecomputercover.See"Removingthecover"onpage68.

2.Removethefrontbezel.See"Removingandreplacingthefrontbezel"onpage71.

3.Disconnectthefrontfanassemblycablefromthepowerfanconnectoronthesystemboard.See

"Locatingpartsonthesystemboard"onpage71

4.Thefrontfanassemblyisattachedtothechassisbyfourrubbermounts.Removethefrontfanassembly

bygentlypullingitoutofthechassis.

Chapter8ReplacingFRUs(Types7061,7090,9353,9421,9485,9623,9625,9705,9786,9795,9935,9946,9953)87
