Chapter9.ReplacingFRUs(Types7057,7062,7092,9342,
9344,9354,9426,9486,9624,9707,9787,9804,9945)
Important
BeforeyoureplaceanyFRU,readChapter2"Safetyinformation"onpage3.Theseprecautionsand
guidelineswillhelpyouworksafely.
FRUreplacementsaretobedonebytrainedservicetechniciansonly.
ThischapterdoesnotcontainaremoveandreplaceprocedureforallFRUs.OnlythemajorFRUsare
documented.
Rearconnectors
Thefollowingillustrationshowsthelocationsoftheconnectorsontherearofthecomputer.
1
Standardmouseconnector
10
PCIExpress16xadapterconnector
2
Parallelconnector
11
PCIExpressx1adapterconnector
3
USBconnectors(4)
12
Audiolineoutconnector
4
Ethernetconnector
13
Microphoneconnector
5
Serialconnector(somemodels)
14
USBconnectors(2)
6
Audiolineinconnector
15
VGAmonitorconnector
7
Powercordconnector
16
DVImonitorconnector
