1.Removecover.See"Removingthecover"onpage94.
2.Removethedrivebayassembly.See"Accessingsystemboardcomponentsanddrives"onpage96.
3.Removetheharddiskdrive.See"Replacingtheharddiskdrive"onpage106.
4.Disconnectthepowerswitch/LEDassemblycablefromthesystemboard.See"Locatingpartsonthe
systemboard"onpage95.
5.Removethescrewthatsecuresthepowerswitch/LEDassemblytothechassis.
6.Notethepowerswitch/LEDassemblycableroutingandremovetheassemblyfromthechassis.
7.Routethecableforthenewpowerswitch/LEDassemblythroughtheholeinthechassisandtothe
systemboard.
8.Installthepowerswitch/LEDassemblyintothechassisandsecuretheassemblywiththescrew.
9.Connectthepowerswitch/LEDcabletothesystemboard.
10.Reinstalltheharddiskdrive.See"Replacingtheharddiskdrive"onpage106.
11.Alignthedrivebayassemblywiththetwoslotsandrailsonthesidesofthechassisslidethedrivebay
assemblytowardstherearofthechassisuntilitsnapsintoposition.
12.Reinstallthefrontbezel.
13.Goto"CompletingtheFRUreplacement"onpage113.
Replacingthefrontpanelcard
Attention
Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe"Importantsafetyinformation"
intheThinkCentreSafetyandWarrantyGuidethatcamewithyourcomputer.ToobtainacopyoftheThinkCentre
SafetyandWarrantyGuide,goto:http://www.lenovo.com/support
Thissectionprovidesinformationonhowtoremoveandreplacethefrontpanelcard.
Toremoveorreplacethefrontpanelcard,dothefollowing:
1.Removecover.See"Removingthecover"onpage94.
2.Removethedrivebayassembly.See"Accessingsystemboardcomponentsanddrives"onpage96.
3.Disconnectthefrontpanelassemblycablesfromthesystemboard.See"Locatingpartsonthesystem
board"onpage95
.
4.Removethescrewthatsecuresthefrontpanelcardassemblytothechassis.
110ThinkCentreHardwareMaintenanceManual
