3658VistaHomePremium64RecoveryCDsFRU#CRU
US(models)
71Y66341
French(models)
71Y66351
3658Win7Professional32FRU#CRU
BrazilianPortuguese(allmodels)
89Y04541
MachineType7057
Item
#7057FRUsFRU#CRU
1
AMD89W&65W4Pinheatsink(allmodels)
41R64072
2
Microprocessor,Athlon644800+X2(2.50GHz,1ML2,65W)G165nm(models)43C4093
N
2
Microprocessor,Athlon645000+X2(2.60GHz,1ML2,65W)G165nm(modelsA6G
A2UA2F)
41X1427N
2
Microprocessor,Athlon1640B(2.70GHz,512KL2,45W)G265nm(modelsA5GA3U
A3FA8SA8PA8DA8YCTO)
45R6488N
2
Microprocessor,Athlon645200+AM2X2(2.7GHzprocessor,65W)steppingG165nm
(models)
45C7502
N
2
Microprocessor,Athlon645400BX2(2.80GHz,1ML2,65W)G265nm(modelsB7U
B7F)
45R6486N
2
Microprocessor,Athlon645600+X2(2.90GHz,1ML2,89W)G265nm(modelsCTO)45C7504
N
2
Microprocessor,AthlonX2BE2350(2.1GHzprocessor,45W,1MBL2)stepingG1
(models)
43C6166
N
2
Microprocessor,AthlonX2BE2400(2.3GHzprocessor,45W,1MBL2)stepingG1
(models)
43C6165
N
2
Microprocessor,Athlon4450BX2(2.30GHz,1ML2,45W)G265nm(modelsBBU
BBFB9G)
46R3624N
2
Microprocessor,Athlon5000BX2(2.60GHz,1ML2,65W)G265nm(modelsA6GA2U
A2FB5UB5FB6UB6F)
46R3625N
Chapter10FRUlists141
