MachineType9342
Item
#9342FRUsFRU#CRU
1
Heatsink,AMD89W&65W4Pinheatsink(allmodels)
41R64072
2
Microprocessor,Athlon644800+X2(2.50GHz,1ML2,65W)G165nm(models)43C4093
N
2
Microprocessor,Athlon645000+X2(2.60GHz,1ML2,65W)G165nm(modelsA1J
A3SA3PA3DA3Y)
41X1427N
2
Microprocessor,Athlon1640B(2.70GHz,512KL2,45W)G265nm(modelsB9CCTO)
45R6488N
2
Microprocessor,Athlon645200+AM2X2(2.7GHzprocessor,65W)steppingG165nm
(models)
45C7502
N
2
Microprocessor,Athlon645400BX2(2.80GHz,1ML2,65W)G265nm(modelsA9J
B1JB3JB4JB6JB7JD7JD8J)
45R6486N
2
Microprocessor,Athlon645600+X2(2.90GHz,1ML2,89W)G265nm(models)45C7504
N
2
Microprocessor,AthlonX2BE2350(2.1GHzprocessor,45W,1MBL2)stepingG1
(models)
43C6166
N
2
Microprocessor,AthlonX2BE2400(2.3GHzprocessor,45W,1MBL2)stepingG1
(models)
43C6165
N
2
Microprocessor,Athlon4450BX2(2.30GHz,1ML2,45W)G265nm(modelsE2JE3J)
46R3624N
2
Microprocessor,Athlon5000BX2(2.60GHz,1ML2,65W)G265nm(modelsD4M
A7JA8JA1JA3SA3PA3DA3YCTO)
46R3625N
2
Microprocessor,Athlon5200BX2(2.70GHz,1ML2,65W)G265nm(modelsCTO)
46R3626N
2
Microprocessor,AthlonLE-1660(2.8GHz,512KL2,45W)G265nm(modelsCTO)
53Y7722N
2
Microprocessor,AthlonX25600B(2.9GHz,1ML2,65W)G265nm(modelsCTO)
53Y7718N
2
Microprocessor,Athlon64X26000+(3.1GHz,1ML2,89W)G265nm(modelsCTO)
53Y7720N
2
Microprocessor,AthlonIIX2240(2.8GHz,2MTotalCache,AM3,65W)C245nm
(models91Z)
64Y8012N
2
Microprocessor,AthlonIIX2245(2.9GHz,2MTotalCache,AM3,65W)C245nm
(models91Z)
64Y8013N
208ThinkCentreHardwareMaintenanceManual
