9344VistaHomePremium64RecoveryCDsFRU#CRU
US(models)
71Y66341
French(models)
71Y66351
9344Win7Professional32FRU#CRU
BrazilianPortuguese(allmodels)
89Y04541
MachineType9353
Item
#9353FRUsFRU#CRU
1
AMD89W&65W4Pinheatsink(allmodels)
41R64072
2
Microprocessor,Athlon644800+X2(2.50GHz,1ML2,65W)G165nm(models)43C4093
N
2
Microprocessor,Athlon645000+X2(2.60GHz,1ML2,65W)G165nm(models)
41X1427N
2
Microprocessor,Athlon1640B(2.70GHz,512KL2,45W)G265nm(models)
45R6488N
2
Microprocessor,Athlon645200+X2(2.70GHz,1ML2,65W)G165nm(models)45C7502
N
2
Microprocessor,Athlon645400BX2(2.80GHz,1ML2,65W)G265nm(models)
45R6486N
2
Microprocessor,Athlon645600+X2(2.90GHz,1ML2,89W)G265nm(models)45C7504
N
2
Microprocessor,AthlonBE-2350X2(2.10GHz,1ML2,45W)G265nm(models)43C6166
N
2
Microprocessor,AthlonBE-2400X2(2.30GHz,1ML2,45W)G265nm(models)43C6165
N
2
Microprocessor,Athlon4450BX2(2.30GHz,1ML2,45W)G265nm(models)
46R3624N
2
Microprocessor,Athlon5000BX2(2.60GHz,1ML2,65W)G265nm(models)
46R3625N
234ThinkCentreHardwareMaintenanceManual
