Updating(ashing)BIOSfromadiskette

1.Insertasystemprogramupdate(ash)disketteintothediskettedrive.systemprogramupdatesare

availableathttp://www.lenovo.com/supportontheWorldWideWeb.

2.Turnonthecomputer.Ifitisalreadyon,youmustturnitoffandbackon.Theupdatebegins.

3.Followtheinstructionsonthescreentocompletetheupdate.

RecoveringfromaPOST/BIOSupdatefailure

IfthepowertoyourcomputerisinterruptedwhilePOST/BIOSisbeingupdated(ashupdate),yourcomputer

mightnotrestartcorrectly.Ifthishappens,performthefollowingprocedurewhichiscommonlycalled

Boot-blockRecovery.

1.Turnoffthecomputerandanyattacheddevices,suchasprinters,monitors,andexternaldrives.

2.Unplugallpowercordsfromelectricaloutletsandremovethecomputercover.Referto"Removing

thecover"onpage68.

3.Accessthesystemboard.Referto"Locatingpartsonthesystemboard"onpage71.

4.LocatetheClearCMOS/Recoveryjumperonthesystemboard.Referto"Locatingpartsonthesystem

board"onpage71.

5.RemoveanycablesthatimpedeaccesstotheClearCMOS/Recoveryjumper.

6.Movethejumperfromthestandardposition(pin1andpin2)topin2andpin3.

7.Reconnectanycablesthatweredisconnected.Referto"CompletingtheFRUreplacement"onpage91.

8.Closethecomputercoverandreconnectthepowercordsforthecomputerandmonitortoelectrical

outlets.

9.InsertthePOST/BIOSupdate(ash)oppydisketteorCD-ROMintothedrive,andturnonthecomputer

andthemonitor.

10.Therecoverysessionwilltaketwotothreeminutes.Duringthistimeyouwillhearaseriesofbeeps.After

theupdatesessioniscompleted,therewillbenovideo,theseriesofbeepswillend,andthesystemwill

automaticallyturnoff.Removethediskettefromthediskettedriveordiscfromtheopticaldrive.

11.Repeatsteps2through5onpage468.

12.ReplacetheClearCMOS/Recoveryjumpertothestandardposition(pin1andpin2).

13.Reconnectanycablesthatweredisconnected.Referto"CompletingtheFRUreplacement"onpage91.

14.Closethecomputercoverandreconnectthepowercordsforthecomputerandmonitortoelectrical

outlets.

15.Turnonthecomputertorestarttheoperatingsystem.

Powermanagement

Powermanagementreducesthepowerconsumptionofcertaincomponentsofthecomputersuchasthe

systempowersupply,processor,harddiskdrives,andsomemonitors.

Automaticcongurationandpowerinterface(ACPI)BIOS

BeinganACPIBIOSsystem,theoperatingsystemisallowedtocontrolthepowermanagementfeatures

ofthecomputerandthesettingforAdvancedPowerManagement(APM)BIOSmodeisignored.Not

alloperatingsystemssupportACPIBIOSmode.

AutomaticPower-Onfeatures

TheAutomaticPower-OnfeatureswithinthePowerManagementmenuallowyoutoenableanddisable

featuresthatturnonthecomputerautomatically.

468ThinkCentreHardwareMaintenanceManual
