5 Motor control (MCTRL)
5.8 Monitoring
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.8 Monitoring
Many monitoring functions that are integrated into the controller can detect errors and thus protect
the device/motor from damage or overload.
• Detailed information on the individual monitoring functions can be found in the following sub-
chapters.
Parameterisable responses
If a monitoring function trips, the response set via the corresponding parameter is carried out. The
following responses can be selected:
• "No response": Response/monitoring is deactivated.
• "Fault": Change of the operating status by a pulse inhibit of the power output stage.
• "Warning": Operating status of the controller remains unchanged. Only a message is entered
into the logbook of the controller.
Related topics:
Device states
( 53)
Diagnostics & error management
( 145)
Basics on error handling in the controller
( 145)
Error messages of the operating system
( 156)
5.8.1 Device overload monitoring (Ixt)
In C064/1...3 displays the device utilisation (ixt) in [%] in different time intervals:
• If the device utilisation reaches the switch-off threshold set in C123
:
• The error response set in C604
will be carried out (Lenze setting: "Warning").
•The "OC5: Ixt overload
" error message will be entered into the logbook.
• A setting of C604
= "0: No Reaction" deactivates the monitoring.
Monitoring Response
(Lenze setting)
Parameter
Device overload monitoring (Ixt)
Warning C604
Motor load monitoring (I2xt) Warning C606
Brake resistor monitoring (I2xt) No Reaction C574
Mains phase failure monitoring Warning C565
Parameter Info
C064/1 Device utilisation (Ixt)
• Maximum value of the pulse utilisation (C064/2
)
and permanent utilisation (C064/3
).
C064/2 Device utilisation (Ixt) 15s
• Pulse utilisation over the last 15 seconds (only for loads >160 %).
C064/3 Device utilisation (Ixt) 3 min
• Permanent utilisation over the last 3 minutes.
Highlighted in grey = display parameter
