7 Drive application
7.3 Setting parameters (short overview)
132
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.3 Setting parameters (short overview)
Parameter Info Lenze setting
Value Unit
C012 Accel. time - main setpoint 2.0 s
C013
Decel. time - main setpoint 2.0 s
C182
S-ramp time PT1 20.00 s
C134
Ramp smoothing - main setpoint 0: Off
C019
Auto-DCB: Threshold 3 rpm
C036
DCB: Current 50.0 %
C039/1
Fixed setpoint 1 40.0 %
C039/2
Fixed setpoint 2 60.0 %
C039/3 Fixed setpoint 3 80.0 %
C105
Deceleration time - quick stop 5.0 s
C106
Auto-DCB: Hold time 0.5 s
C107 DCB: Hold time 999.0 s
C222
L_PCTRL_1: Vp 1.0
C223
L_PCTRL_1: Tn 400 ms
C224
L_PCTRL_1: Kd 0.0
C225
L_PCTRL_1: MaxLimit 199.9 %
C226
L_PCTRL_1: MinLimit -199.9 %
C227
L_PCTRL_1: Acceleration time 0.1 s
C228
L_PCTRL_1: Deceleration time 0.1 s
C231/1
L_PCTRL_1: Pos. maximum 199.9 %
C231/2
L_PCTRL_1: Pos. minimum 0.0 %
C231/3
L_PCTRL_1: Neg. minimum 0.0 %
C231/4
L_PCTRL_1: Neg. maximum 199.9 %
C242 L_PCTRL_1: Operating mode 0: Off
C243
L_PCTRL_1: Acceleration time influence 5.0 s
C244
L_PCTRL_1: Deceleration time influence 5.0 s
C245 L_PCTRL_1: PID output value - %
C800
L_MPot_1: Upper limit 100.0 %
C801
L_MPot_1: Lower limit -100.0 %
C802 L_MPot_1: Acceleration time 10.0 s
C803
L_MPot_1: Deceleration time 10.0 s
C804
L_MPot_1: Inactive function 0: Retain value
C805
L_MPot_1: Init function 0: Load last value
C806
L_MPot_1: Use 0: No
