7 Drive application
7.3 Setting parameters (short overview)
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 134
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.4.2 Output connections
Configuration pa-
rameters
Identifier Control mode
10 (terminals 0)
See fig. [7-1]
12 (Terminal 2) 14 (terminals 11) 16 (terminals 16) 20 (keypad) 21 (PC) 30 (CAN)
See fig. [7-2]
C620/5 LS_DisFree: wDis1 (C481/1) - - - - wDeviceStateWord -
C620/6
LS_DisFree: wDis2 (C481/2) -------
C620/7
LS_DisFree: wDis3 (C481/3) -------
C620/8
LS_DisFree: wDis4 (C481/4) -------
C620/9
LS_DisFree_a: nDis1_a (C482/1) - - - - nMotorSpeedAct_a -
C620/10
LS_DisFree_a: nDis2_a (C482/2) ---- nOutputSpeedCtrl_a -
C620/11
LS_DisFree_a: nDis3_a (C482/3) -------
C620/12
LS_DisFree_a: nDis4_a (C482/4) -------
C620/20
LP_CanOut1: wState ------wDeviceStateWord
C620/21
LP_CanOut1: wOut2 ------nMotorSpeedAct_a
C620/22
LP_CanOut1: wOut3 ------nOutputSpeedCtrl_a
C620/23
LP_CanOut1: wOut4 -------
C620/24
LP_CanOut2: wOut1 -------
C620/25
LP_CanOut2: wOut2 -------
C620/26
LP_CanOut2: wOut3 -------
C620/27
LP_CanOut2: wOut4 -------
C621/1
LS_DigitalOutput:bRelay (X101) bDriveFail bDriveFail
C621/2
LS_DigitalOutput:bOut1 (X4/DO1) bDriveReady bDriveReady
C621/6
USER-LED bNactCompare bNactCompare
C621/7
LA_NCtrl: bStatusBit0 -------
C621/8
LA_NCtrl: bStatusBit2 bImaxActive bImaxActive
C621/9
LA_NCtrl: bStatusBit3 bSpeedSetReached bSpeedSetReached
C621/10
LA_NCtrl: bStatusBit4 bSpeedActEqSet bSpeedActEqSet
C621/11
LA_NCtrl: bStatusBit5 bNactCompare bNactCompare
C621/12
LA_NCtrl: bStatusBit14 bSpeedCcw bSpeedCcw
C621/13
LA_NCtrl: bStatusBit15 bDriveReady bDriveReady
C621/16
LS_DisFree_b: bDis1 (C480/Bit0) ---- bDriveReady -
C621/17
LS_DisFree_b: bDis2 (C480/Bit1) ---- bDriveFail -
C621/18
...
C621/23
LS_DisFree_b: bDis3 (C480/Bit2)
...
LS_DisFree_b
: bDis8 (C480/Bit7)
-------
C621/30...45
LP_CanOut1: bState_B0 ... B15 -------
C621/46...61
LP_CanOut2: bOut1_B0 ... B15 -------
