8 Diagnostics & error management
8.7 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.7.1.2 Error subject area
The error subject area indicates the internal "function unit" of the controller in which the error has
occurred:
8.7.1.3 Error ID
16-bit value (0 ... 65535) for error identification within the error subject area.
Error subject area Assigned errors Remedy possible by
user?
No. Name
111 Supply voltage Errors that occur in connection with the supply voltage of the device. Yes
119 Temperature Errors that occur for temperature reasons. Yes
123 Motor management / encoder Errors that occur within the motor control or encoder evaluation. Yes
125 Analog I/O Errors that occur in connection with the analog inputs and outputs. Yes
131 CAN general Errors related to general CAN functions. Yes
135 CAN PDO Errors that are explicitly only related to the CAN-PDO (process data
objects).
Yes
144 Parameter set Errors that occur in connection with the parameter set or the parame-
ter set memory (memory module).
Yes if the error relates to a
missing or incompatible
memory module.
145 Device firmware (internal error) Internal error of the device firmware. No
400 Device hardware defective Errors that occur due to defective device hardware. No
980 US01: User error 1 Errors generated by the user (by the application) via the
LS_SetError_1
system block.
Yes
981 US02: User error 2
