10 Parameter reference
10.1 Structure of the parameter descriptions
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10.1 Structure of the parameter descriptions
Each parameter is described in the Parameter list in the form of a table which consists of the follo-
wing three areas:
Table header
The table header contains the following general information:
• Parameter number (Cxxxxx)
• Parameter name (display text in the »Engineer» and keypad)
• Data type
• Parameter index in decimal and hexadecimal notation for access via a fieldbus (e.g. CAN system
bus).
 Tip!
The parameter index is calculated as follows:
• Index [dec] = 24575 - code
• Index [hex] = 0x5FFF - code
Example for code C00005:
• Index [dec] = 24575 - 5 = 24570
• Index [hex] = 0x5FFF - 0x{5} = 0x5FFA
Table contents
The table contains further general explanations & notes on the parameter and the possible settings,
which are represented in different ways depending on the parameter type:
• Parameters with read-only access
• Parameters with write access
Table footer
The table footer contains the Parameter attributes
.
