Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 233
10 Parameter reference
10.1 Structure of the parameter descriptions
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10.1.3.4 Parameters with subcodes
Description structure
Parameter setting in the »Engineer«
The »Engineer« parameter list displays each subcode individually. The parameters are set as descri-
bed in the previous chapters.
Parameter | Name:
Cxxxxx | _____________
Data type: _______
Index: _______
Description
Setting range
(min. value | unit | max. value)
Subcodes Lenze setting
Cxxxxx/1
Cxxxxx/2
Cxxxxx/3
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
