10 Parameter reference
10.2 Parameter list | C00114
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00114
C00118
Parameter | Name:
C00114 | DIx inversion
Data type: UNSIGNED_16
Index: 24461
d
= 5F8D
h
Polarity of the digital inputs
• Every digital input of the device can be inverted with regard to polarity via this bit field.
Digital terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x8000 (decimal: 32768)
Value is bit-coded: ( =bit set) Info
Bit 0  DI1 inverted Inversion of digital input 1
Bit 1  DI2 inverted Inversion of digital input 2
Bit 2  DI3 inverted Inversion of digital input 3
Bit 3  DI4 inverted Inversion of digital input 4
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Reserved
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  RFR inverted Inversion of RFR digital input (controller enable)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00118 | DOx inversion
Data type: UNSIGNED_8
Index: 24457
d
= 5F89
h
Polarity of the digital outputs
• Every digital output of the device can be inverted with regard to polarity via this bit field.
Digital terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: ( =bit set) Info
Bit 0  Relay inverted Relay inversion
Bit 1  DO1 inverted Inversion of digital output 1
Bit 2  Reserved
Bit 3  Reserved
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
