10 Parameter reference
10.2 Parameter list | C00182
263
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00182
C00200
C00201
C00203
C00222
Parameter | Name:
C00182 | S-ramp time PT1
Data type: INTEGER_16
Index: 24393
d
= 5F49
h
FB L_NSet_1: PT1 S-ramp time for the main setpoint ramp function generator
• Only effective with activated ramp smoothing (C00134
="1").
Setting range (min. value | unit | max. value) Lenze setting
0.01 s 50.00 20.00 s
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00200 | Firmware product type
Data type: VISIBLE_STRING
Index: 24375
d
= 5F37
h
Display of the firmware product type
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00201 | Firmware compile date
Data type: VISIBLE_STRING
Index: 24374
d
= 5F36
h
Display of the firmware compilation date
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00203 | Product type code
Data type: VISIBLE_STRING
Index: 24372
d
= 5F34
h
As of version 03.00.00
Display of the single device component types
Subcodes Info
C00203/1 Reserved
C00203/2 Reserved
C00203/3 Reserved
C00203/4 Type: I/O micro
C00203/5 Type: Memory module
C00203/6 Type: Safety module
C00203/7 Reserved
C00203/8 Type: Complete device
C00203/9 Reserved
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00222 | L_PCTRL_1: Vp
Data type: INTEGER_16
Index: 24353
d
= 5F21
h
FB L_PCTRL_1: Gain factor Vp for the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.1 500.0 1.0
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10
