Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 266
10 Parameter reference
10.2 Parameter list | C00242
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00242
C00243
C00244
C00245
C00308
Parameter | Name:
C00242 | L_PCTRL_1: Operating mode
Data type: UNSIGNED_8
Index: 24333
d
= 5F0D
h
FB L_PCTRL_1: Selection of the operating mode
• Depending on the selection, the blue switches in the displayed signal flow are set accordingly in the Engineer on
the Application parameter tab in the Overview Signal flow Process controller dialog level.
Selection list (Lenze setting printed in bold) Info
0Off The input setpoint nNSet_a is output without any chan-
ges at the output nOut_a.
1 Additive + feedforward control nNSet_a and nAct_a are used as PID input values. The ar-
riving nNSet_a is additively linked to the value output by
the PID element.
2 PID as setpoint generator. nSet_a and nAct_a are used as PID input values. The in-
put nNSet_a is not considered.
3 PID setpoint from L_NSet_1 nNSet_a and nAct_a are used as PID input values. The in-
put nSet_a is not considered.
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00243 | L_PCTRL_1: Acceleration time influence
Data type: UNSIGNED_32
Index: 24332
d
= 5F0C
h
FB L_PCTRL_1: Acceleration time for showing the PID output value
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 5.0 s
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C00244 | L_PCTRL_1: Deceleration time influence
Data type: UNSIGNED_32
Index: 24331
d
= 5F0B
h
FB L_PCTRL_1: Deceleration time for masking out the PID output value
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 5.0 s
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C00245 | L_PCTRL_1: PID output value
Data type: INTEGER_16
Index: 24330
d
= 5F0A
h
FB L_PCTRL_1: Display of the output value of the PID process controller
Display range (min. value | unit | max. value)
-199.9 % 199.9
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00308 | Activation of internal features
Data type: UNSIGNED_16
Index: 24267
d
= 5ECB
h
This code is for device-internal use only and must not be written to by the user!
