Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 27
3 Commissioning
3.3 Commissioning with integrated keypad
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.3 Commissioning with integrated keypad
Only a few parameters need to be adapted for the drive. Afterwards, the drive application can be im-
mediately controlled via the digital and analog inputs of the controller in the preset control mode
"Terminals 0".
Commissioning steps
In the following, commissioning of the controller using the integrated keypad is described step by
step. Please process the chapters consecutively and execute all steps carefully. This procedure will
help you to commission the controller quickly and as safe as possible:
Load Lenze setting
Parameterise drive/application ( 28)
Save parameter settings safe against mains failure
( 29)
Enable controller and select speed
( 30)
3.3.1 Load Lenze setting
In order to achieve a defined device configuration, it is advisable to make sure that the device is in
its original delivery state. For this purpose, the "Load Lenze setting" device command is available.
Information on how to use the integrated keypad can be found in the chapter entitled
"Internal Keypad
". ( 17)
Step Info
1. Mains on After the mains has been switched on and the keypad self test has been completed,
"00" is displayed
2. ↵ After pressing the enter key:
Without password protection you have free access from here to all menus (and thus
all parameters).
3. Select menu -2-.
• The menu -2- contains parameters for quick commissioning with terminal cont-
rol.
4. ↵ Confirm selection.
5. ↵ Confirm first code C002
("device commands") of the menu -2-.
6. ↵ Confirm subcode c001 ("load Lenze setting").
7. Set value "01" (≡ "Start").
8. ↵ Accept parameter setting to execute the "Load Lenze setting" device command.
