Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 276
10 Parameter reference
10.2 Parameter list | C00409
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00409
Parameter | Name:
C00409 | LP_CanIn Mapping
Data type: UNSIGNED_16
Index: 24166
d
= 5E66
h
As of version 03.00.00
Mapping for port blocks LP_CanIn1 and LP_CanIn2
System bus "CAN on board": Port blocks
Setting range (min. value | unit | max. value)
0 65535
Subcodes Lenze setting Info
C00409/1 0 LP_CanIn1_wIn1(wCtrl)
C00409/2 0 LP_CanIn1_wIn2
C00409/3 0 LP_CanIn1_wIn3
C00409/4 0 LP_CanIn1_wIn4
C00409/5 0 LP_CanIn2_wIn1
C00409/6 0 LP_CanIn2_wIn2
C00409/7 0 LP_CanIn2_wIn3
C00409/8 0 LP_CanIn2_wIn4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
