10 Parameter reference
10.3 Table of attributes
300
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10.3 Table of attributes
The table of attributes contains information that is required for a communication to the controller
via parameters.
How to read the table of attributes:
Column Meaning Entry
Code Parameter name Cxxxxx
Name Parameter short text (display text) Text
Index dec Index under which the parameter is addressed.
The subindex of array variables corresponds to the
Lenze subcode number.
24575 - Lenze code number Is only required for access via a bus sys-
tem.
hex 5FFF
h
- Lenze code number
Data DS Data structure E Single variable
(only one parameter element)
A Array variable
(several parameter elements)
DA Number of array elements (subcodes) Number
DT Data type INTEGER_16 2 bytes with sign
INTEGER_32 4 bytes with sign
UNSIGNED_8 1 byte without sign
UNSIGNED_16 2 bytes without sign
UNSIGNED_32 4 bytes without sign
VISIBLE_STRING ASCII string
Factor Factor for data transfer via a bus system, depen-
ding on the number of decimal positions
Factor 1 ≡ no decimal positions
10 ≡ 1 decimal position
100 ≡ 2 decimal positions
1000 ≡ 3 decimal positions
Access R Read access Reading permitted
W Write access Writing permitted
CINH Controller inhibit required Writing is only possible when the controller is inhibited
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
C00002
Device commands 24573 5FFD A 32 UNSIGNED_8 1
C00003
Status of last device command 24572 5FFC E 1 UNSIGNED_8 1
C00006
Motor control 24569 5FF9 E 1 UNSIGNED_8 1
C00007
Control mode 24568 5FF8 E 1 UNSIGNED_16 1
C00010
Minimum analog setpoint 24565 5FF5 A 1 INTEGER_16 100
C00011
Appl.: Reference speed 24564 5FF4 E 1 UNSIGNED_16 1
C00012
Accel. time - main setpoint 24563 5FF3 E 1 UNSIGNED_32 1000
C00013
Decel. time - main setpoint 24562 5FF2 E 1 UNSIGNED_32 1000
C00015
VFC: V/f base frequency 24560 5FF0 E 1 UNSIGNED_16 10
C00016
VFC: Vmin boost 24559 5FEF E 1 UNSIGNED_16 100
C00018
Switching frequency 24557 5FED E 1 UNSIGNED_8 1
C00019
Auto-DCB: Threshold 24556 5FEC E 1 UNSIGNED_16 1
C00021
Slip comp. 24554 5FEA E 1 INTEGER_16 100
C00022
Imax in motor mode 24553 5FE9 E 1 UNSIGNED_16 100
C00023
Imax in generator mode 24552 5FE8 E 1 INTEGER_16 100
C00024
Comparison value N_Act 24551 5FE7 E 1 INTEGER_16 100
C00026
AINx: Offset 24549 5FE5 A 1 INTEGER_16 100
C00027
AINx: Gain 24548 5FE4 A 1 INTEGER_32 100
C00028 AINx: Input voltage 24547 5FE3 A 1 INTEGER_16 100
C00029
AINx: Input current 24546 5FE2 A 1 INTEGER_16 100
C00033
AINx: Output value 24542 5FDE A 1 INTEGER_16 100
C00034 AINx: Configuration 24541 5FDD A 1 UNSIGNED_8 1
