Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 301
10 Parameter reference
10.3 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00036 DCB: Current 24539 5FDB E 1 INTEGER_16 100
C00039
Fixed setpoint x (L_NSet_1 n-Fix) 24536 5FD8 A 3 INTEGER_16 100
C00050
MCTRL: Speed setpoint 24525 5FCD E 1 INTEGER_32 1
C00051
MCTRL: Actual speed value 24524 5FCC E 1 INTEGER_32 1
C00052
Motor voltage 24523 5FCB E 1 UNSIGNED_16 1
C00053
DC-bus voltage 24522 5FCA E 1 UNSIGNED_16 1
C00054
Motor current 24521 5FC9 E 1 UNSIGNED_16 100
C00056
Torque 24519 5FC7 A 2 INTEGER_32 100
C00057
Maximum torque 24518 5FC6 E 1 UNSIGNED_32 100
C00058
Output frequency 24517 5FC5 E 1 INTEGER_32 100
C00059
Appl.: Reference frequency C11 24516 5FC4 E 1 UNSIGNED_32 100
C00061
Heatsink temperature 24514 5FC2 E 1 INTEGER_16 1
C00064
Device utilisation (Ixt) 24511 5FBF A 3 INTEGER_16 100
C00066
Thermal motor load (I²xt) 24509 5FBD E 1 INTEGER_16 100
C00073
Vp Imax controller 24502 5FB6 E 1 UNSIGNED_16 100
C00074
Ti Imax controller 24501 5FB5 E 1 UNSIGNED_16 1
C00081
Rated motor power 24494 5FAE E 1 UNSIGNED_16 100
C00084
Motor stator resistance 24491 5FAB E 1 UNSIGNED_32 1
C00085
Motor stator leakage inductance 24490 5FAA E 1 UNSIGNED_16 100
C00087
Rated motor speed 24488 5FA8 E 1 UNSIGNED_16 1
C00088
Rated motor current 24487 5FA7 E 1 UNSIGNED_16 100
C00089
Rated motor frequency 24486 5FA6 E 1 UNSIGNED_16 1
C00090
Rated motor voltage 24485 5FA5 E 1 UNSIGNED_16 1
C00091
Motor cosine phi 24484 5FA4 E 1 UNSIGNED_8 100
C00092
Motor magnetising inductance 24483 5FA3 E 1 UNSIGNED_16 10
C00093
Power section identification 24482 5FA2 E 1 UNSIGNED_16 1
C00094
Password 24481 5FA1 E 1 INTEGER_32 1
C00095
Motor magnetising current 24480 5FA0 E 1 UNSIGNED_16 100
C00097
Rated motor torque 24478 5F9E E 1 UNSIGNED_32 100
C00098
Rated device current 24477 5F9D E 1 UNSIGNED_16 10
C00099
Firmware version 24476 5F9C E 1 VISIBLE_STRING
C00100
Firmware version 24475 5F9B A 4 UNSIGNED_8 1
C00105
Deceleration time - quick stop 24470 5F96 E 1 UNSIGNED_32 1000
C00106
Auto-DCB: Hold time 24469 5F95 E 1 UNSIGNED_32 1000
C00107
DCB: Hold time 24468 5F94 E 1 UNSIGNED_32 1000
C00114
DIx inversion 24461 5F8D E 1 UNSIGNED_16
C00118
DOx inversion 24457 5F89 E 1 UNSIGNED_8
C00120
Motor overload threshold (I²xt) 24455 5F87 E 1 INTEGER_16 100
C00122
Initial value motor overload (I²xt) 24453 5F85 A 1 UNSIGNED_16 100
C00123
Device utilisat. threshold (Ixt) 24452 5F84 E 1 INTEGER_16 100
C00134
Ramp smoothing - main setpoint 24441 5F79 E 1 UNSIGNED_8 1
C00136
Communication control words 24439 5F77 A 2 UNSIGNED_16
C00137
Device state 24438 5F76 E 1 UNSIGNED_16 1
C00141
Device settings 24434 5F72 A 1 UNSIGNED_8 1
C00142
Auto-start option 24433 5F71 E 1 UNSIGNED_8
C00144
Switching frequency reduction (temp.) 24431 5F6F E 1 UNSIGNED_8 1
C00150
Status word 24425 5F69 E 1 UNSIGNED_16
C00155
Status word 2 24420 5F64 E 1 UNSIGNED_16
C00158
Cause of controller inhibit 24417 5F61 E 1 UNSIGNED_16
C00159
Cause of quick stop QSP 24416 5F60 E 1 UNSIGNED_16
C00165
Error information 24410 5F5A A 1 VISIBLE_STRING
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
