10 Parameter reference
10.3 Table of attributes
302
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00166 Error information text 24409 5F59 A 3 VISIBLE_STRING
C00168
Error number 24407 5F57 A 8 UNSIGNED_32 1
C00169
Time of error 24406 5F56 A 8 UNSIGNED_32 1
C00170
Error counter 24405 5F55 A 8 UNSIGNED_8 1
C00173
Mains voltage 24402 5F52 E 1 UNSIGNED_8 1
C00174
Reduced brake chopper threshold 24401 5F51 E 1 UNSIGNED_8 1
C00177
Switching cycles 24398 5F4E A 2 UNSIGNED_32 1
C00178
Elapsed-hour meter 24397 5F4D E 1 UNSIGNED_32 1
C00179
Power-on time meter 24396 5F4C E 1 UNSIGNED_32 1
C00182
S-ramp time PT1 24393 5F49 E 1 INTEGER_16 100
C00200
Firmware product type 24375 5F37 E 1 VISIBLE_STRING
C00201
Firmware compile date 24374 5F36 E 1 VISIBLE_STRING
C00203
Product type code 24372 5F34 A 9 VISIBLE_STRING
C00222
L_PCTRL_1: Vp 24353 5F21 E 1 INTEGER_16 10
C00223
L_PCTRL_1: Tn 24352 5F20 E 1 UNSIGNED_16 1
C00224
L_PCTRL_1: Kd 24351 5F1F E 1 UNSIGNED_16 10
C00225
L_PCTRL_1: MaxLimit 24350 5F1E E 1 INTEGER_16 100
C00226
L_PCTRL_1: MinLimit 24349 5F1D E 1 INTEGER_16 100
C00227
L_PCTRL_1: Acceleration time 24348 5F1C E 1 UNSIGNED_32 1000
C00228
L_PCTRL_1: Deceleration time 24347 5F1B E 1 UNSIGNED_32 1000
C00231
L_PCTRL_1: Operating range 24344 5F18 A 4 INTEGER_16 100
C00234
Oscillation damping influence 24341 5F15 E 1 UNSIGNED_16 100
C00242
L_PCTRL_1: Operating mode 24333 5F0D E 1 UNSIGNED_8 1
C00243
L_PCTRL_1: Acceleration time influ-
ence
24332 5F0C E 1 UNSIGNED_32 1000
C00244
L_PCTRL_1: Deceleration time influ-
ence
24331 5F0B E 1 UNSIGNED_32 1000
C00245
L_PCTRL_1: PID output value 24330 5F0A E 1 INTEGER_16 100
C00322
Transmission mode CAN TxPDOs 24253 5EBD A 2 UNSIGNED_8 1
C00323
Transmission mode CAN Rx PDOs 24252 5EBC A 2 UNSIGNED_8 1
C00324
CAN transmit blocking time 24251 5EBB A 3 UNSIGNED_16 1
C00345
CAN error status 24230 5EA6 E 1 UNSIGNED_8 1
C00347
CAN status HeartBeat producer 24228 5EA4 A 1 UNSIGNED_8 1
C00350
CAN node address 24225 5EA1 E 1 UNSIGNED_8 1
C00351
CAN baud rate 24224 5EA0 E 1 UNSIGNED_8 1
C00352
CAN slave/master 24223 5E9F E 1 UNSIGNED_8 1
C00353
CAN IN/OUT COBID source 24222 5E9E A 2 UNSIGNED_8 1
C00354
COBID 24221 5E9D A 4 UNSIGNED_32
C00355
Active COBID 24220 5E9C A 4 UNSIGNED_16 1
C00356
CAN time settings 24219 5E9B A 5 UNSIGNED_16 1
C00357
CAN monitoring times 24218 5E9A A 2 UNSIGNED_16 1
C00359
CAN status 24216 5E98 E 1 UNSIGNED_8 1
C00360
CAN telegram counter 24215 5E97 A 12 UNSIGNED_16 1
C00364
CAN MessageError 24211 5E93 E 1 UNSIGNED_8
C00366
Number of CAN SDO channels 24209 5E91 E 1 UNSIGNED_8 1
C00367
CAN Sync-Rx identifier 24208 5E90 E 1 UNSIGNED_16 1
C00368
CAN Sync-Tx Identifier 24207 5E8F E 1 UNSIGNED_16 1
C00369
CAN Sync transmission cycle time 24206 5E8E E 1 UNSIGNED_16 1
C00372
CAN_Tx_Rx_Error 24203 5E8B A 2 UNSIGNED_8 1
C00381
CAN Heartbeat Producer time 24194 5E82 E 1 UNSIGNED_16 1
C00385
CAN NodeID Heartbeat producer 24190 5E7E A 1 UNSIGNED_8 1
C00386
ConsumerTime HeartBeat Producer 24189 5E7D A 1 UNSIGNED_16 1
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
