User guide

11 Function library
11.1 L_MPot_1
306
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameter
Identifier
Data type
Value/meaning
nOut_a
INT
Output signal
Parameter Possible settings Info
C800
-199.9 % 199.9 Upper limit
• Lenze setting: 100.0 %
C801
-199.9 % 199.9 Lower limit
• Lenze setting: -100.0 %
C802
0.1 s 999.9 Acceleration time
• Lenze setting: 10.0 s
C803
0.1 s 999.9 Deceleration time
• Lenze setting: 10.0 s
C804
Inactive function
• Selection of response when deac-
tivating the motor potentiometer
via the input bInAct.
0Keep value
(Lenze setting)
No further action; nOut_a retains its
value.
1 Deceleration to 0 The motor potentiometer returns to
0 % within the deceleration time T
if
.
2 Deceleration to lower limit The motor potentiometer runs
within the deceleration time T
if
to
the lower limit value (C801
).
3Without ramp to 0 Important for the emergency stop
function
The motor potentiometer output im-
mediately changes to 0 %
4 Without ramp to lower limit The motor potentiometer output im-
mediately changes to the lower limit
value (C801
).
5 Acceleration to upper limit The motor potentiometer runs with
the acceleration time T
ir
to the upper
limit value (C800
).
C805
Init function
• Selection of response when swit-
ching on the device.
0 Load last value
(Lenze setting)
The output value being output du-
ring mains power-off is saved non-
volatilely in the internal memory of
the controller. It will be reloaded du-
ring mains power-on.
1 Load lower limit The lower limit value (C801
) is loaded
during mains power-on.
2 Load 0 An output value = 0 % is loaded du-
ring mains power-on.
