• The change from one state to another is done in a 1 ms cycle. If, at the same time, several state
change requests exist, the state with the higher priority is processed first (see the following ta-
ble).
• C137
displays the current device state.
• C150
(status word) provides a bit coded representation of the current device state via bits 8 ... 11
(see table below).
[4-1] Device states, priorities, and meaning of the status bits in the status word
ID Device state
(Display in C137
)
Priority Status bits
(display in C150
)
Meaning
Bit 11 Bit 10 Bit 9 Bit 8
0 - (reserved) - 0 0 0 0 -
1 Init
- 0 0 0 1 Initialisation is active
2 MotorIdent
- 0 0 1 0 Motor parameter identification is acti-
ve
3 ReadyToSwitchON
Prio 4 0 0 1 1 Device is ready to start
4 SwitchedON
Prio 3 0 1 0 0 Device is switched on
5 OperationEnabled
Prio 1 0 1 0 1 Operation
6 - (reserved) - 0 1 1 0 -
7 Trouble
Prio 2 0 1 1 1 Trouble is active
8 Fault
Prio 6 1 0 0 0 Fault is active
9 - (reserved) - 1 0 0 1 -
10 SafeTorqueOff
Prio 5 1 0 1 0 Safe torque off is active
11 - (reserved) - 1 0 1 1 -
... ... ... ... ...
15 - (reserved) - 1 1 1 1 -
