5 Motor control (MCTRL)
64 Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5 Motor control (MCTRL)
This chapter provides information on the parameter setting of the controller's internal motor cont-
rol.
Topics:
Motor selection/Motor data
Selecting the control mode
Defining current and speed limits
V/f characteristic control (VFCplus)
Sensorless vector control (SLVC)
Parameterisable additional functions
Braking operation/braking energy management
Monitoring
