8.2 FIF_CAN2_IO (node number: 35)
System bus (CAN) for Lenze PLC devices
FIF−CAN system blocks
8−2
L
PLC−Systembus EN 2.0
8.2.1 FIF_Inputs_CAN2
Variable Data type Signal type Address Display code Display
format
Notes
FIF_CAN2_nInW1_a
Integer Analog
%IW35.0 C2492/4
dec [%]
FIF_CAN2_nInW2_a %IW35.1 C2492/5
FIF_CAN2_bInB0_b
Bool Binary
%IX35.0.0
hex
... ... C2491/3
FIF_CAN2_bInB15_b %IX35.0.15
FIF_CAN2_bInB16_b %IX35.1.0
... ... C2491/4
FIF_CAN2_bInB31_b %IX35.1.15
FIF_CAN2_dnInD1_p Double integer Position %ID35.0 − −
FIF_CAN2_nInW3_a
Integer Analog
%IW35.2 C2492/6
dec [%]
FIF_CAN2_nInW4_a %IW35.3 C2492/7
8.2.2 FIF_Outputs_CAN2
Variable Data type Signal type Address Display code Display
format
Notes
FIF_CAN2_nOutW1_a
Integer Analog
%QW35.0 C2493/4
dec [%]
FIF_CAN2_nOutW2_a %QW35.1 C2493/5
FIF_CAN2_bFDO0_b
Bool Binary
%QX35.0.0
− −
... ...
FIF_CAN2_bFDO15_b %QX35.0.15
FIF_CAN2_bFDO16_b %QX35.1.0
... ...
FIF_CAN2_bFDO31_b %QX35.1.15
FIF_CAN2_dnOutD1_p Double integer Position %QD35.0 − −
FIF_CAN2_nOutW3_a
Integer Analog
%QW35.2 C2493/6
dec [%]
FIF_CAN2_nOutW4_a %QW35.3 C2493/7
8.2.3 Process data telegram
The process data telegram consists of an identifier and 8 bytes of user data.
11bit 8 bytes user data
Identifier Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Information on the identifier can be found in chapter 2.4.1. (^ 2−3)
