9.1 CANaux1_IO (node number: 34)
System bus (CAN) for Lenze PLC devices
CAN−AUX system blocks
9−2
L
PLC−Systembus EN 2.0
9.1.1 Inputs_CANaux1
Variable Data type Signal type Address Display code Display
format
Notes
CANaux1_nInW0_a Integer Analog %IW34.0
CANaux1_bInB0_b %IX34.0.0
... Bool Binary ... C2491/1 hex
CANaux1_bInB15_b %IX34.0.15
CANaux1_nInW1_a Integer Analog %IW34.1 C2492/1 dec [%]
CANaux1_bInB16_b %IX34.1.0
... Bool Binary ... C2491/2 hex
CANaux1_bInB31_b %IX34.1.15
CANaux1_nInW2_a Integer Analog %IW34.2 C2492/2 dec [%]
CANaux1_bInB32_b %IX34.2.0
... Bool Binary ...
CANaux1_bInB47_b %IX34.2.15
CANaux1_nInW3_a Integer Analog %IW34.3 C2492/3 dec [%]
CANaux1_bInB48_b %IX34.3.0
... Bool Binary ...
CANaux1_bInB63_b %IX34.3.15
CANaux1_dnInD1_p Double integer Position %ID34.1
9.1.2 Outputs_CANaux1
Variable Data type Signal type Address Display code Display
format
Notes
CANaux1_nOutW0_a Integer Analog %QW34.0 − −
CANaux1_bFDO0_b
Bool Binary
%QX34.0.0
− −
.. ..
CANaux1_bFDO15_b %QX34.0.15
CANaux1_nOutW1_a Integer Analog %QW34.1 C2493/1 dec [%]
CANaux1_bFDO16_b
Bool Binary
%QX34.1.0
− −
.. ..
CANaux1_bFDO31_b %QX34.1.15
CANaux1_nOutW2_a Integer Analog %QW34.2 C2493/2 dec [%]
CANaux1_bFDO32_b
Bool Binary
%QX34.2.0
− −
.. ..
CANaux1_bFDO47_b %QX34.2.15
CANaux1_nOutW3_a Integer Analog %QW34.3 C2493/3 dec [%]
CANaux1_bFDO48_b
Bool Binary
%QX34.3.0
− −
.. ..
CANaux1_bFDO63_b %QX34.3.15
CANaux1_dnOutD1_p Double integer Position %QD34.1 − −
