System bus (CAN) for Lenze PLC devices
"CAN" system bus interface configuration
3−5
l
PLC−Systembus EN 2.0
· Please note that the identifier of the telegram to be transmitted has to comply with the
identifier of the process data input object to be activated.
· In the case of an individual address allocation, the identifier for the process data objects is
composed as follows:
Identifier + 384 ) value of C0354/x
x = subcode
· Thus, identifiers in the range of 385 ... 896 can be allocated for the process data objects.
3.4.2 Display of the identifier set
Via C0355 you can have the identifier displayed which is set for the process data objects.
· C0355 is a display code, settings cannot be carried out via C0355.
Code LCD
Possible settings
Information
Lenze Selection
C0355
1
2
3
4
5
6
CAN Id
CAN1_IN Id
CAN1_OUT Id
CAN2_IN Id
CAN2_OUT Id
CAN3_IN Id
CAN3_OUT Id
g
385 {1} 896 System bus identifier
for the process data objects
CAN1_IN
CAN1_OUT
CAN2_IN
CAN2_OUT
CAN3_IN
CAN3_OUT
