System bus (CAN) for Lenze PLC devices
Configuration (CAN−AUX interface)
6−8
l
PLC−Systembus EN 2.0
6.8 Reset node
Changes with regard to the CAN baud rate, the node addresses, and the identifiers only are accepted
after a reset node.
A reset node can be effected by
· Reconnection of the mains
· Reset node command via NMT command. (^ 2−6)
· Reset node command via the CANaux_Management SB (^ 8−4)
· Reset node via C2458:
Code LCD
Possible settings
Information
Lenze Selection
C2458 Reset node 0 0 No function
1 CANaux reset node
CANauxreset node
6.9 System bus management
Via the CANaux_Management SB,
· a reset node can be activated.
· "Communication error" and "Bus off state" can be processed in the PLC program.
· the instant of transmission of CANaux2_OUT and CANaux3_OUT can be influenced.
Tip!
Detailed information on the CANaux_Management SB can be found in chapter 8.4. (^ 8−4)
