11.3 Parameters of the communication module for slot MXI2
This chapter lists the parameters of the E94AYCEP communication module (POWERLINK) for slot
MXI2 of the Servo Drive 9400 in numerically ascending order.
C14000
C14001
Parameter | Name:
C14000 | EPL IP address
Data type: UNSIGNED_32
Index: 10575 = 0x294F
EPL index: See subcodes
The code displays the IP address of the communication module.
• The IP address is derived from the EPL node address (Node ID): 192.168.100.[Node ID]
• The node ID is derived from the DIP switch position or from C14044
.
Node address setting
( 36)
Setting range (min. value | unit | max. value)
0.0.0.0
(0x00000000)
255.255.255.255
(0xFFFFFFFF)
Subcodes Lenze setting Info EPL index
C14000/1 3232261130
(0xC0A86401 = 192.168.100.1)
EPL IP address 0x1E40.0x02
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14001 | EPL IP subnet mask
Data type: UNSIGNED_32
Index: 10574 = 0x294E
EPL index: See subcodes
The code declares the IP subnet mask which restricts the directly addressable IP address range (i.e. without a
gateway in the EPL segment of the routers). The value 255.255.255.0 (0xFFFFFF00) is always assigned to the subnet
mask in one segment.
Setting range (min. value | unit | max. value)
255.0.0.0
(0xFF000000)
255.255.255.0
(0xFFFFFF00)
Subcodes Lenze setting Info EPL index
C14001/1 4294967040
(0xFFFFFF00 = 255.255.255.0)
EPL IP-subnet mask 0x1E40.0x03
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
