11 Parameter reference
11.3 Parameters of the communication module for slot MXI2
115
Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14103
C14104
C14105
C14110
Parameter | Name:
C14103 | EPL NMT command: Enable
Data type: UNSIGNED_8
Index: 10472 = 0x28E8
EPL index: 0x1F9F.0x01
The code enables the NMT command defined via C14104/C14105. The values have the following meaning:
• 0: The command is inhibited.
• 1: The command is enabled.
After the NMT command has been executed, the code is automatically set to FALSE.
NMT commands can cause serious faults in the network. Cycle and monitoring errors can occur.
Setting range (min. value | unit | max. value) Lenze setting
010
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14104 | EPL NMT command: Command ID
Data type: UNSIGNED_8
Index: 10471 = 0x28E7
EPL index: 0x1F9F.0x02
The code defines the command to be executed.
NMT commands can cause serious faults in the network. Cycle and monitoring errors can occur.
Selection list (Lenze setting printed in bold)
34 StopNode
40 ResetNode
41 ResetCommunication
42 ResetConfiguration
255 No command
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14105 | EPL NMT command: Target address
Data type: UNSIGNED_8
Index: 10470 = 0x28E6
EPL index: 0x1F9F.0x03
The code defines the destination node of the command via its node address. The node address "255" addresses all
EPL nodes of the network. "0" is an invalid address, a command with destination node "0" is ineffective.
NMT commands can cause serious faults in the network. Cycle and monitoring errors can occur.
Setting range (min. value | unit | max. value) Lenze setting
0 255 0
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14110 | EPL fault memory
Data type: INTEGER_8
Index: 10465 = 0x28E1
EPL index: 0x1001
The code indicates the currently pending errors (according to error classes).
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
