Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17 116
11 Parameter reference
11.3 Parameters of the communication module for slot MXI2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14115
C14116
C14117
Parameter | Name:
C14115 | EPL MN: Frame error (CRC)
Data type: UNSIGNED_32
Index: 10460 = 0x28DC
EPL index: See subcodes
The POWERLINK telegrams of the EPL network are protected by a checksum. The Managing Node counts the
checksum errors which signalise a falsification of the frame.
The monitoring response is determined via C14891/4
.
Setting range (min. value | unit | max. value)
0 4294967295
Subcodes Lenze setting Info EPL index
C14115/1 0 CumulativeCnt_U32 0x1C00.0x01
C14115/2 0 ThresholdCnt_U32 0x1C00.0x02
C14115/3 9 Threshold_U32 0x1C00.0x03
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14116 | EPL MN: Frame collisions
Data type: UNSIGNED_32
Index: 10459 = 0x28DB
EPL index: See subcodes
The code indicates the collision counter of the Managing Node.
The Managing Node detects frame collisions in the EPL segment. This code contains the number of detected
collisions.
Each event is counted. Every single event is followed by an error message. No threshold value management is
implemented.
Due to extended topology options of EPL compared to the standard Ethernet according to IEEE802.3 it is not
mandatory that the Managing Node recognises all collisions that occur in the segment.
Setting range (min. value | unit | max. value)
0 4294967295
Subcodes Lenze setting Info EPL index
C14116/1 0 CumulativeCnt_U32 0x1C01.0x01
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14117 | EPL MN: Cycle time violation
Data type: UNSIGNED_32
Index: 10458 = 0x28DA
EPL index: See subcodes
The code indicates the counters of the Managing Node for cycle time overflows.
The monitoring response is determined via C14891/1
.
Setting range (min. value | unit | max. value)
0 4294967295
Subcodes Lenze setting Info EPL index
C14117/1 0 CumulativeCnt_U32 0x1C02.0x01
C14117/2 0 ThresholdCnt_U32 0x1C02.0x02
C14117/3 9 Threshold_U32 0x1C02.0x03
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
