Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17 122
11 Parameter reference
11.3 Parameters of the communication module for slot MXI2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14229
C14231
C14232
C14233
Parameter | Name:
C14229 | EPL multi-stage node declaration MN
Data type: UNSIGNED_8
Index: 10346 = 0x286A
EPL index: See subcodes
This code indicates in which multiplexed cycle the node is queried. The value entered must not exceed the value in
code C14074
.
If, for instance, the value "3" is entered in code C14074
, the multiplexed cycle is repeated every three cycles. If now
the value "3" is entered for one node in C14229/x, it is always queried only in the second cycle of the three
multiplexed cycles.
Setting range (min. value | unit | max. value)
0 Cycles 255
Subcodes Lenze setting Info EPL index
C14229/1 0 cycles Managing Node 0x1F9B.0xF0
C14229/2 0 cycles Diagnostics device 0x1F9B.0xFD
C14229/3 0 cycles router 0x1F9B.0xFE
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14231 | EPL RPDO
Data type: UNSIGNED_64
Index: 10344 = 0x2868
EPL index: See subcodes
EPL RPDO-1
Subcodes Lenze setting Info EPL index
C14231/1 0 EPL RPDO 0x1600.0x01
... ... ... ...
C14231/32 0 EPL RPDO 0x1600.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14232 | EPL RPDO
Data type: UNSIGNED_64
Index: 10343 = 0x2867
EPL index: See subcodes
EPL RPDO-2
Subcodes Lenze setting Info EPL index
C14232/1 0 EPL RPDO 0x1601.0x01
... ... ... ...
C14232/32 0 EPL RPDO 0x1601.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C14233 | EPL RPDO
Data type: UNSIGNED_64
Index: 10342 = 0x2866
EPL index: See subcodes
EPL RPDO-3
Subcodes Lenze setting Info EPL index
C14233/1 0 EPL RPDO 0x1602.0x01
... ... ... ...
C14233/32 0 EPL RPDO 0x1602.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
