11 Parameter reference
11.4 Table of attributes
133
Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13219 EPL device type MN 11356 0x2C5C A 3 UNSIGNED_32
C13225
EPL MN: max. data RPDO 11350 0x2C56 A 3 UNSIGNED_16 1
C13226
EPL status list MN 11349 0x2C55 A 3 UNSIGNED_8
C13228
EPL Time-out isochronous comm. 11347 0x2C53 A 3 UNSIGNED_32 1
C13229
EPL multi-stage node declaration MN 11346 0x2C52 A 3 UNSIGNED_8 1
C13231
EPL RPDO 11344 0x2C50 A 32 UNSIGNED_64
C13232
EPL RPDO 11343 0x2C4F A 32 UNSIGNED_64
C13233
EPL RPDO 11342 0x2C4E A 32 UNSIGNED_64
C13234
EPL RPDO 11341 0x2C4D A 32 UNSIGNED_64
C13235
EPL RPDO 11340 0x2C4C A 32 UNSIGNED_64
C13236
EPL RPDO 11339 0x2C4B A 32 UNSIGNED_64
C13237
EPL RPDO 11338 0x2C4A A 32 UNSIGNED_64
C13238
EPL RPDO 11337 0x2C49 A 32 UNSIGNED_64
C13239
EPL RPDO 11336 0x2C48 A 32 UNSIGNED_64
C13240
EPL RPDO 11335 0x2C47 A 32 UNSIGNED_64
C13484
EPL address: RPDO 11091 0x2B53 A 10 UNSIGNED_8 1
C13489
EPL RPDO: object count 11086 0x2B4E A 10 UNSIGNED_8 1
C13531
EPL TPDO 11044 0x2B24 A 32 UNSIGNED_64
C13789
EPL TPDO: object count 10786 0x2A22 A 1 UNSIGNED_8 1
C13880
EPL quality lights 10695 0x29C7 E 1 UNSIGNED_8
C13881
EPL reset error counter 10694 0x29C6 E 1 UNSIGNED_8 1
C13882
EPL reset cycle counter 10693 0x29C5 E 1 UNSIGNED_8 1
C13883
EPL response when "DataExchange" is
quit
10692 0x29C4 E 1 UNSIGNED_8 1
C13885
EPL data RPDO: error response 10690 0x29C2 E 1 UNSIGNED_8 1
C13891
EPL module error response 10684 0x29BC A 5 UNSIGNED_8 1
C13900
EPL firmware type 10675 0x29B3 E 1 VISIBLE_STRING
C13901
EPL firmware date 10674 0x29B2 E 1 VISIBLE_STRING
C13902
EPL firmware version 10673 0x29B1 E 1 VISIBLE_STRING
C13910
EPL module error 10665 0x29A9 E 1 UNSIGNED_32
C13911
EPL module warning 10664 0x29A8 E 1 UNSIGNED_32
C13919
EPL additional error info 10656 0x29A0 E 1 UNSIGNED_32
C13920
EPL DIP switch 10655 0x299F E 1 UNSIGNED_8
C14000
EPL IP address 10575 0x294F A 1 UNSIGNED_32
C14001
EPL IP subnet mask 10574 0x294E A 1 UNSIGNED_32
C14003
EPL IP router address 10572 0x294C A 1 UNSIGNED_32
C14004
EPL MAC address 10571 0x294B A 1 OCTET_STRING
C14027
EPL MN start-up 10548 0x2934 E 1 UNSIGNED_32
C14028
EPL node declaration CN 10547 0x2933 A 100 UNSIGNED_32
C14029
EPL node declaration MN 10546 0x2932 A 3 UNSIGNED_32
C14030
EPL device type 10545 0x2931 E 1 UNSIGNED_32
C14034
EPL identity object 10541 0x292D A 1 UNSIGNED_32
C14035
EPL device type CN 10540 0x292C A 100 UNSIGNED_32
C14040
EPL Feature Flags 10535 0x2927 E 1 UNSIGNED_32
C14041
EPL version 10534 0x2926 E 1 UNSIGNED_8
C14042
Current EPL device address 10533 0x2925 E 1 UNSIGNED_8 1
C14043
EPL device address selection 10532 0x2924 E 1 UNSIGNED_8 1
C14044
EPL device address SW 10531 0x2923 E 1 UNSIGNED_8 1
C14045
EPL host name 10530 0x2922 E 1 VISIBLE_STRING
C14060
EPL cycle time 10515 0x2913 E 1 UNSIGNED_32
C14062
EPL MN: boot timing 10513 0x2911 A 5 UNSIGNED_32 1
Code Name Index Data Access
dec hex DS DA Data type Factor R W CINH
