10.1 Error messages of the communication module
This chapter describes all error messages of the communication module and their causes and
remedies.
10.1.1 Short overview
The following table contains all error messages of the communication module in numerical order of
the error numbers. Moreover the preset error response and - if applicable - the parameters for
setting the error response are specified.
Tip!
If you click on the cross-reference in the first column, you will get a detailed description
(causes and remedies) of the corresponding error message.
Error number Name Response (Lenze setting) Adjustable in
hex dec
0x00c83100
13119744 EPL: Lost connection to 9400 target No response -
0x00c85531
13129009 EPL: Memory access error Information -
0x00c85532
13129010 EPL: Memory: Read error Information -
0x00c85533
13129011 EPL: Memory: Write error Information -
0x00c86010
13131792 EPL: Internal watchdog activated Fault -
0x00c86011
13131793 EPL: Internal watchdog activated Fault -
0x00c86100
13132032 EPL: Internal error Information -
0x00c86101
13132033 EPL: Internal error Fault -
0x00c86110
13132048 EPL: Invalid PDO mapping detected Warning Locked -
0x00c8641f
13132831 EPL: Invalid parameter set Fault -
0x00c86420
13132832 EPL: Lenze settings loaded Fault -
0x00c88130
13140272 EPL: Fieldbus watchdog activated Fault
0x00c88131
13140273 EPL: DataExchange exited No response C13883 /
C14883
0x00c88261 13140577 EPL: Invalid address selected Fault -
0x00c88263
13140579 EPL MN: Network has not been started (bootup-1) Warning Locked C13891/2 /
C14891/2
0x00c88264 13140580 EPL MN: Not all nodes are in the operational status (bootup-2) Warning Locked C13891/2 /
C14891/2
0x00c88265 13140581 EPL: Synchronisation of MN lost Warning Locked C13891/3 /
C14891/3
0x00c88266 13140582 EPL: Defective telegram (CRC) detected Warning Locked C13891/4 /
C14891/4
0x00c88267 13140583 EPL: Failure of a network node No response C13891/5 /
C14891/5
0x00c88281 13140609 EPL: Cycle time exceeded Warning Locked C13891/1 /
C14891/1
0x00c88283 13140611 EPL: MN address assigned double Fault -
0x00c88284
13140612 EPL: Internal error Fault -
