10 Error messages
10.1 Error messages of the communication module
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
EPL: Fieldbus watchdog activated [0x00c88130]
EPL: DataExchange exited [0x00c88131]
EPL: Invalid address selected [0x00c88261]
EPL MN: Network has not been started (bootup-1) [0x00c88263]
EPL MN: Not all nodes are in the operational status (bootup-2) [0x00c88264]
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  warning  Information
Cause Remedy
Communication module is defective. Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold) Setting: C13883 / C14883 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The POWERLINK data exchange has been terminated. • Check wiring.
• Plug network cable into POWERLINK terminal X211 or
X212.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
An invalid IP address has been assigned by the Managing
Node via POWERLINK or set as node ID.
• Ensure that a valid IP address is assigned by the
Managing Node via POWERLINK.
• Set valid node ID.
Node address setting
( 36)
Response (Lenze setting printed in bold) Setting: C13891/2 / C14891/2
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• The Managing Node could not start the POWERLINK
network.
• Not all required nodes were found.
• Check if all nodes are switched on
• Check address setting and wiring.
Monitoring functions of the Managing Node
( 46)
Response (Lenze setting printed in bold) Setting: C13891/2 / C14891/2
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The Managing Node could not transfer all nodes into the
"NMT_CS_OPERATIONAL" status via process data
exchange.
Check whether single nodes are in error status.
Monitoring functions of the Managing Node
( 46)
